h stock standard, ) check stock EU, f check stock JP, m stock exhaustion M TCTR Ø Hole Ø(tolerance)(mm)(mm)CodeTHCHT(chamfer)LF(mm)THL(mm) LU(mm) LS DCON K(mm)(mm)(mm)LK(mm)NOFTypeStock Intro JIS M3X0.5 P2 2.5 2.56 2101101035 2.5P 100 5 18 40 4 3.2 6 3 010 h M4X0.7 P2 3.3 3.38 2101101042 2.5P 100 7 21 40 5 4 7 3 010 h SP M5X0.8 P2 4.2 4.28 2101101049 2.5P 100 9 25 40 5.5 4.5 7 3 010 h M6X1 P2 5 5.09 2101101055 2.5P 100 11 30 40 6 4.5 7 3 010 h M8X1.25 P3 6.8 6.85 2101101064 2.5P 150 12 - 50 6.2 5 8 3 011 h M10X1.5 P3 8.5 8.6 2101101078 2.5P 150 13 - 50 7 5.5 8 3 011 h SL M12X1.75 P4 10.3 10.36 2101101088 2.5P 150 15 - 50 8.5 6.5 9 3 011 h M14X2 P4 12 12.12 2101101100 2.5P 150 18 - 60 10.5 8 11 3 011 f M16X2 P4 14 14.12 2101101114 2.5P 150 18 - 60 12.5 10 13 3 011 h PO MF TCTR Ø Hole Ø(tolerance)(mm)(mm)CodeTHCHT(chamfer)LF(mm)THL(mm) LU(mm) LS DCON K(mm)(mm)(mm)LK(mm)NOFTypeStock JIS M3X0.35 P2 2.65 2.7 2101101036 2.5P 100 5 18 40 4 3.2 6 3 010 f ST M4X0.5 P2 3.5 3.56 2101101043 2.5P 100 5 21 40 5 4 7 3 010 f M5X0.5 P2 4.5 4.56 2101101051 2.5P 100 6 25 40 5.5 4.5 7 3 010 f M6X0.75 P2 5.25 5.33 2101101056 2.5P 100 8 30 40 6 4.5 7 3 010 ) M6X0.5 P2 5.5 5.56 2101101057 2.5P 100 8 30 40 6 4.5 7 3 010 f ROLL M8X1 P3 7 7.09 2101101065 2.5P 150 12 - 50 6.2 5 8 3 011 ) M10X1.25 P3 8.8 8.85 2101101079 2.5P 150 13 - 50 7 5.5 8 3 011 ) M10X1 P3 9 9.09 2101101080 2.5P 150 13 - 50 7 5.5 8 3 011 f CARBIDE M12X1.5 P3 10.5 10.6 2101101089 2.5P 150 15 - 50 8.5 6.5 9 3 011 ) M12X1.25 P3 10.8 10.85 2101101090 2.5P 150 15 - 50 8.5 6.5 9 3 011 ) M14X1.5 P3 12.5 12.6 2101101102 2.5P 150 14 - 60 10.5 8 11 3 011 ) M16X1.5 P3 14.5 14.6 2101101116 2.5P 150 14 - 60 12.5 10 13 3 011 ) LONG JIS HAND TAPS EG (STI) SPECIAL THREADS, GAUGES THREAD MILLS DIES CENTER DRILLS Technical info 439
