h stock standard, ) check stock EU, f check stock JP, m stock exhaustion M TCTR Ø Hole Ø(tolerance)(mm)(mm)CodeTHCHT(chamfer)LF(mm)THL(mm) LU(mm) LS DCON K(mm)(mm)(mm)LK(mm)NOFTypeStock Intro JIS M3X0.5 P3 2.5 2.56 SY3.0GRKWB 2.5P 46 11 - - 4 3.2 6 3 001 f M4X0.7 P3 3.3 3.38 SY4.0IRKWB 2.5P 52 13 - - 5 4 7 3 001 f SP M5X0.8 P3 4.2 4.28 SY5.0KRKWB 2.5P 60 16 - - 5.5 4.5 7 3 001 f M6X1 P3 5 5.09 SY6.0MRKWB 2.5P 62 19 - - 6 4.5 7 3 004 f M8X1.25 P3 6.8 6.85 SY8.0NRKWB 2.5P 70 22 - - 6.2 5 8 3 007 f M10X1.5 P3 8.5 8.6 SY010ORKWB 2.5P 75 24 - - 7 5.5 8 3 007 f SL M12X1.75 P4 10.3 10.36 SY012PSKWB 2.5P 82 30 - - 8.5 6.5 9 3 007 f M14X2 P4 12 12.12 SY014QSKWB 2.5P 88 30 - - 10.5 8 11 3 007 f M16X2 P4 14 14.12 SY016QSKWB 2.5P 95 30 - - 12.5 10 13 3 007 f PO M18X2.5 P4 15.5 15.63 SY018RSKWB 2.5P 100 35 - - 14 11 14 4 007 f M20X2.5 P4 17.5 17.63 SY020RSKWB 2.5P 105 35 - - 15 12 15 4 007 f MF TCTR Ø Hole Ø(tolerance)(mm)(mm)CodeTHCHT(chamfer)LF(mm)THL(mm) LU(mm) LS DCON K(mm)(mm)(mm)LK(mm)NOFTypeStock ST JIS M10X1.25 P3 8.8 8.85 SY010NRKWB 2.5P 75 22 - - 7 5.5 8 3 007 f M12X1.5 P4 10.5 10.6 SY012OSKWB 2.5P 82 24 - - 8.5 6.5 9 3 007 f M12X1.25 P4 10.8 10.85 SY012NSKWB 2.5P 80 22 - - 8.5 6.5 9 3 007 f ROLL M14X1.5 P4 12.5 12.6 SY014OSKWB 2.5P 88 24 - - 10.5 8 11 3 007 f M16X1.5 P4 14.5 14.6 SY016OSKWB 2.5P 95 24 - - 12.5 10 13 3 007 f M18X1.5 P4 16.5 16.6 SY018OSKWB 2.5P 95 24 - - 14 11 14 4 007 f CARBIDE M20X1.5 P4 18.5 18.6 SY020OSKWB 2.5P 95 24 - - 15 12 15 4 007 f JIS LONG HAND TAPS EG (STI) SPECIAL THREADS, GAUGES THREAD MILLS DIES CENTER DRILLS Technical info 417
