| M | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock | Intro |
| JIS | ||||||||||||||||
| M2X0.4 | P4 | 1.6 | 1.65 | TPLM2.0E3 | 3P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | |
| M2.3X0.4 | P4 | 1.9 | 1.95 | TPLM2.3E3 | 3P | 42 | 7.2 | 12 | 27 | 3 | 2.5 | 5 | 3 | 001 | f | SP |
| M2.5X0.45 | P4 | 2.1 | 2.11 | TPLM2.5F3 | 3P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | |
| M2.6X0.45 | P4 | 2.2 | 2.21 | TPLM2.6F3 | 3P | 46 | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 3 | 001 | f | |
| M3X0.5 | P5 | 2.5 | 2.56 | TPLM3.0G3 | 3P | 46 | 9 | 14 | 26 | 4 | 3.2 | 6 | 4 | 001 | f | |
| M3.5X0.6 | P5 | 2.9 | 2.97 | TPLM3.5H3 | 3P | 52 | 11 | 16 | 29 | 5 | 4 | 7 | 4 | 001 | f | SL |
| M4X0.7 | P5 | 3.3 | 3.38 | TPLM4.0I3 | 3P | 52 | 11 | 17 | 29 | 5 | 4 | 7 | 4 | 001 | f | |
| M5X0.8 | P5 | 4.2 | 4.28 | TPLM5.0K3 | 3P | 60 | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 4 | 001 | f | |
| M6X1 | P5 | 5 | 5.09 | TPLM6.0M3 | 3P | 62 | 15 | 26 | 33 | 6 | 4.5 | 7 | 4 | 001 | f | PO |
| M8X1.25 | P6 | 6.8 | 6.85 | TPLM8.0N3 | 3P | 70 | 19 | - | 36 | 6.2 | 5 | 8 | 4 | 002 | f |
