h stock standard, ) check stock EU, f check stock JP, m stock exhaustion M TCTR Ø Hole Ø(tolerance)(mm)(mm)CodeTHCHT(chamfer)LF(mm)THL(mm) LU(mm) LS DCON K(mm)(mm)(mm)LK(mm)NOFTypeStock Intro DIN 371 M2X0.4 ISO2X(6HX) 1.6 1.65 TD2.0EBLEN5 5P 45 8 - 32 2.8 2.1 5 3 001 f M2.5X0.45 ISO2X(6HX) 2.1 2.11 TD2.5FBLEN5 5P 50 8 15 33 2.8 2.1 5 3 057 f SP M3X0.5 ISO2X(6HX) 2.5 2.56 TD3.0GBLEN5 5P 56 9 18 34 3.5 2.7 6 3 057 h M4X0.7 ISO2X(6HX) 3.3 3.38 TD4.0IBLEN5 5P 63 13 21 38 4.5 3.4 6 3 057 h M5X0.8 ISO2X(6HX) 4.2 4.28 TD5.0KBLEN5 5P 70 14 25 39 6 4.9 8 3 057 h M6X1 ISO2X(6HX) 5 5.09 TD6.0MBLEN5 5P 80 15 30 45 6 4.9 8 3 057 h SL M8X1.25 ISO2X(6HX) 6.8 6.85 TD8.0NBLEN5 5P 90 19 35 47 8 6.2 9 3 084 h M10X1.5 ISO2X(6HX) 8.5 8.6 TD010OBLEN5 5P 100 23 39 52 10 8 11 4 084 h M TCTR Ø Hole Ø(tolerance)(mm)(mm)CodeTHCHT(chamfer)LF(mm)THL(mm) LU(mm) LS DCON K(mm)(mm)(mm)LK(mm)NOFTypeStock PO DIN 376 M12X1.75 ISO2X(6HX) 10.3 10.36 TG012PBLEN5 5P 110 26 - 56 9 7 10 4 086 h M14X2 ISO2X(6HX) 12 12.12 TG014QBLEN5 5P 110 26 - 56 11 9 12 4 086 f ST M16X2 ISO2X(6HX) 14 14.12 TG016QBLEN5 5P 110 26 - 56 12 9 12 4 086 f DIN ROLL CARBIDE LONG HAND TAPS EG (STI) SPECIAL THREADS, GAUGES THREAD MILLS DIES CENTER DRILLS Technical info 291
