| Intro | UNC | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | LT ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock |
| JIS | |||||||||||||||||
| No.12-24UNC | P2 | 4.5 | 4.53 | SPQUNCM | 2.5P | 62 | - | 15 | 26 | 33 | 6 | 4.5 | 7 | 3 | 001 | ) | |
| SP | 1/4-20UNC | P2 | 5.1 | 5.19 | SPQU04N | 2.5P | 62 | - | 15 | 26 | 33 | 6 | 4.5 | 7 | 3 | 001 | f |
| JIS | 5/16-18UNC | P2 | 6.6 | 6.65 | SPQU05O | 2.5P | 70 | - | 19 | - | 36 | 6.2 | 5 | 8 | 3 | 013 | f |
| 3/8-16UNC | P2 | 8 | 8.07 | SPQU06P | 2.5P | 75 | - | 23 | - | 38 | 7 | 5.5 | 8 | 3 | 013 | f | |
| 7/16-14UNC | P3 | 9.4 | 9.45 | SPRU07Q | 2.5P | 82 | - | 26 | - | 42 | 8.5 | 6.5 | 9 | 3 | 013 | f | |
| SL | 1/2-13UNC | P3 | 10.9 | 10.91 | SPRU08R | 2.5P | 88 | - | 26 | - | 45 | 10.5 | 8 | 11 | 3 | 013 | f |
| 9/16-12UNC | P3 | 12.2 | 12.33 | SPRU09S | 2.5P | 95 | - | 26 | - | 48 | 12.5 | 10 | 13 | 3 | 013 | f | |
| 5/8-11UNC | P3 | 13.6 | 13.75 | SPRU10U | 2.5P | 95 | - | 26 | - | 48 | 12.5 | 10 | 13 | 3 | 013 | f | |
| PO | 3/4-10UNC | P3 | 16.6 | 16.7 | SPRU12V | 2.5P | 105 | - | 33 | - | 50 | 15 | 12 | 15 | 4 | 013 | f |
| 7/8-9UNC | P3 | 19.6 | 19.61 | SPRU14W | 2.5P | 115 | - | 33 | - | 55 | 17 | 13 | 16 | 4 | 013 | f | |
| 1 -8UNC | P3 | 22.3 | 22.45 | SPRU16X | 2.5P | 125 | - | 39 | - | 58 | 19 | 15 | 18 | 4 | 013 | f | |
| 1 1/8-7UNC | P4 | 25 | 25.17 | SPSU18Y | 2.5P | 135 | - | 46 | - | 62 | 23 | 17 | 20 | 4 | 013 | f | |
| ST | 1 1/4-7UNC | P4 | 28.2 | 28.35 | SPMSU20Y | 2.5P | 145 | - | 46 | - | 67 | 24 | 19 | 22 | 4 | 013 | f |
| 1 3/8-6UNC | P4 | 30.8 | 30.92 | SPMSU22Z | 2.5P | 155 | - | 52 | - | 71 | 28 | 21 | 24 | 4 | 013 | f | |
| 1 1/2-6UNC | P4 | 34 | 34.1 | SPMSU24Z | 2.5P | 165 | - | 52 | - | 76 | 30 | 23 | 26 | 4 | 013 | f | |
| ROLL | 1 3/4-5UNC | P4 | 39.5 | 39.61 | SPMSU280 | 2.5P | 180 | - | 59 | - | 83 | 35 | 26 | 30 | 4 | 013 | f |
| 2 -4.5UNC | P5 | 45.2 | 45.37 | SPTU329 | 2.5P | 195 | - | 70 | - | 85 | 40 | 32 | 35 | 4 | 013 | f | |
| UNF | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | LT ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock | |
| CARBIDE | JIS | ||||||||||||||||
| No.2-64UNF | P1 | 1.85 | 1.87 | SPPUN2D | 2.5P | 42 | - | 8.1 | 12 | 27 | 3 | 2.5 | 5 | 2 | 001 | ) | |
| No.3-56UNF | P1 | 2.1 | 2.15 | SPPUN3E | 2.5P | 46 | - | 8.1 | 14 | 29 | 3 | 2.5 | 5 | 2 | 001 | ) | |
| No.4-48UNF | P1 | 2.4 | 2.41 | SPPUN4F | 2.5P | 46 | - | 9 | 14 | 26 | 4 | 3.2 | 6 | 2 | 001 | ) | |
| LONG | No.5-44UNF | P1 | 2.7 | 2.69 | SPPUN5G | 2.5P | 52 | - | 11 | 16 | 29 | 5 | 4 | 7 | 3 | 001 | ) |
| No.6-40UNF | P1 | 2.9 | 2.97 | SPPUN6H | 2.5P | 52 | - | 11 | 16 | 29 | 5 | 4 | 7 | 3 | 001 | ) | |
| No.8-36UNF | P2 | 3.5 | 3.55 | SPQUN8I | 2.5P | 60 | - | 13 | 21 | 33 | 5.5 | 4.5 | 7 | 3 | 001 | ) | |
| HAND | No.10-32UNF | P2 | 4.1 | 4.12 | SPQUNAJ | 2.5P | 60 | - | 13 | 22 | 33 | 5.5 | 4.5 | 7 | 3 | 001 | ) |
| TAPS | No.12-28UNF | P2 | 4.6 | 4.67 | SPQUNCK | 2.5P | 62 | - | 15 | 26 | 33 | 6 | 4.5 | 7 | 3 | 001 | ) |
| 1/4-28UNF | P2 | 5.5 | 5.53 | SPQU04K | 2.5P | 62 | - | 15 | 26 | 33 | 6 | 4.5 | 7 | 3 | 001 | f | |
| 5/16-24UNF | P2 | 6.9 | 6.97 | SPQU05M | 2.5P | 70 | - | 19 | - | 36 | 6.2 | 5 | 8 | 3 | 013 | f | |
| EG (STI) | 3/8-24UNF | P2 | 8.5 | 8.57 | SPQU06M | 2.5P | 75 | - | 23 | - | 38 | 7 | 5.5 | 8 | 3 | 013 | f |
| 7/16-20UNF | P2 | 9.9 | 9.96 | SPQU07N | 2.5P | 82 | - | 26 | - | 42 | 8.5 | 6.5 | 9 | 3 | 013 | f | |
| 1/2-20UNF | P2 | 11.5 | 11.54 | SPQU08N | 2.5P | 88 | - | 26 | - | 45 | 10.5 | 8 | 11 | 3 | 013 | f | |
| SPECIAL | 9/16-18UNF | P2 | 12.9 | 13 | SPQU09O | 2.5P | 95 | - | 26 | - | 48 | 12.5 | 10 | 13 | 3 | 013 | f |
| THREADS, GAUGES | 5/8-18UNF | P2 | 14.5 | 14.6 | SPQU10O | 2.5P | 95 | - | 26 | - | 48 | 12.5 | 10 | 13 | 3 | 013 | f |
| 3/4-16UNF | P3 | 17.5 | 17.59 | SPRU12P | 2.5P | 105 | - | 33 | - | 50 | 15 | 12 | 15 | 4 | 013 | f | |
| 7/8-14UNF | P3 | 20.5 | 20.57 | SPRU14Q | 2.5P | 115 | - | 33 | - | 55 | 17 | 13 | 16 | 4 | 013 | f | |
| THREAD | 1 -12UNF | P3 | 23.3 | 23.46 | SPRU16S | 2.5P | 125 | - | 39 | - | 58 | 19 | 15 | 18 | 4 | 013 | f |
| MILLS | 1 1/8-12UNF | P3 | 26.5 | 26.63 | SPRU18S | 2.5P | 135 | - | 46 | - | 62 | 23 | 17 | 20 | 4 | 013 | f |
| 1 1/4-12UNF | P3 | 29.6 | 29.81 | SPMRU20S | 2.5P | 145 | - | 46 | - | 67 | 24 | 19 | 22 | 4 | 013 | f | |
| 1 3/8-12UNF | P3 | 32.8 | 32.98 | SPMRU22S | 2.5P | 155 | - | 52 | - | 71 | 28 | 21 | 24 | 4 | 013 | f | |
| DIES | 1 1/2-12UNF | P3 | 36 | 36.16 | SPMRU24S | 2.5P | 165 | - | 52 | - | 76 | 30 | 23 | 26 | 4 | 013 | f |
| UNS | TCTR (tolerance) | Ø (mm) | Hole Ø (mm) | Code | THCHT (chamfer) | LF ( mm ) | LT ( mm ) | THL ( mm ) | LU ( mm ) | LS ( mm ) | DCON ( mm ) | K ( mm ) | LK ( mm ) | NOF | Type | Stock | |
| CENTER | JIS | ||||||||||||||||
| DRILLS | 1 -14UNS | P3 | 23.6 | 23.7 | SPRU16Q | 2.5P | 125 | - | 39 | - | 58 | 19 | 15 | 18 | 4 | 013 | f |
| 1 1/8-14UNS | P3 | 26.75 | 26.8 | SPRU18Q | 2.5P | 135 | - | 46 | - | 62 | 23 | 17 | 20 | 4 | 013 | f |
