Аксессуары - Цанги

Цанги DIN 6499B (ER/ESX)

Артикулммдюйм
ER 11
190011000ø 7-0.5ø 0.276-0.020
190011010ø 1-0.5ø 0.039-0.020
190011015ø 1.5-1ø 0.059-0.039
190011020ø 2-1.5ø 0.079-0.059
190011025ø 2.5-2ø 0.098-0.079
190011030ø 3-2.5ø 0.118-0.098
190011035ø 3.5-3ø 0.138-0.118
190011040ø 4-3.5ø 0.158-0.138
190011045ø 4.5-4ø 0.177-0.158
190011050ø 5-4.5ø 0.197-0.177
190011055ø 5.5-5ø 0.217-0.197
190011060ø 6-5.5ø 0.236-0.217
190011065ø 6.5-6ø 0.256-0.236
190011070ø 7-6.5ø 0.276-0.256
ER 16
190016000ø 10-0.5ø 0.394-0.020
190016010ø 1-0.5ø 0.039-0.020
190016020ø 2-1ø 0.079-0.039
190016030ø 3-2ø 0.118-0.079
190016040ø 4-3ø 0.158-0.118
190016050ø 5-4ø 0.197-0.158
190016060ø 6-5ø 0.236-0.197
190016070ø 7-6ø 0.276-0.236
190016080ø 8-7ø 0.315-0.276
190016090ø 9-8ø 0.354-0.315
190016100ø 10-9ø 0.394-0.354
ER 20
190020000ø 13-1ø 0.512-0.039
190020010ø 1-0.5ø 0.039-0.020
190020020ø 2-1ø 0.079-0.039
190020030ø 3-2ø 0.118-0.079
190020040ø 4-3ø 0.157-0.118
190020050ø 5-4ø 0.197-0.157
190020060ø 6-5ø 0.236-0.197
190020070ø 7-6ø 0.276-0.236
190020080ø 8-7ø 0.315-0.276
190020090ø 9-8ø 0.354-0.315
190020100ø 10-9ø 0.394-0.354
190020110ø 11-10ø 0.433-0.394
190020120ø 12-11ø 0.472-0.433
190020130ø 13-12ø 0.512-0.472
Артикулммдюйм
ER 25
190025000ø 16-1ø 0.630-0.039
190025020ø 2-1ø 0.079-0.039
190025030ø 3-2ø 0.118-0.079
190025040ø 4-3ø 0.157-0.118
190025050ø 5-4ø 0.197-0.157
190025060ø 6-5ø 0.236-0.197
190025070ø 7-6ø 0.276-0.236
190025080ø 8-7ø 0.315-0.276
190025090ø 9-8ø 0.354-0.315
190025100ø 10-9ø 0.394-0.354
190025110ø 11-10ø 0.433-0.394
190025120ø 12-11ø 0.472-0.433
190025130ø 13-12ø 0.512-0.472
190025140ø 14-13ø 0.551-0.512
190025150ø 15-14ø 0.591-0.551
190025160ø 16-15ø 0.630-0.591
ER 32
190032000ø 20-2ø 0.787-0.079
190032030ø 3-2ø 0.118-0.079
190032040ø 4-3ø 0.157-0.118
190032050ø 5-4ø 0.197-0.157
190032060ø 6-5ø 0.236-0.197
190032070ø 7-6ø 0.276-0.236
190032080ø 8-7ø 0.315-0.276
190032090ø 9-8ø 0.354-0.315
190032100ø 10-9ø 0.394-0.354
190032110ø 11-10ø 0.433-0.394
190032120ø 12-11ø 0.472-0.433
190032130ø 13-12ø 0.512-0.472
190032140ø 14-13ø 0.551-0.512
190032150ø 15-14ø 0.591-0.551
190032160ø 16-15ø 0.630-0.591
190032170ø 17-16ø 0.669-0.630
190032180ø 18-17ø 0.709-0.669
190032190ø 19-18ø 0.748-0.709
190032200ø 20-19ø 0.787-0.748
