Contents QT 250 (US specification) Page 4-4 QT/QTS 100 M/MY/MS/MSY Page 5-7 QT/QTS 200, 250 M/MY/MS/MSY Page 8 - 11 QT 200, 250 M/MY/MS/MSY (16D) Page 12 - 14 QT/QTS 300-400 M/MY/MS/MSY Page 15 - 16 QTC/QTE/QTU 100-350 M/MY/MS/MSY Page 17 - 20 QT/QTN 100 MS/MSY (VDI) Page 21 - 24 QT/QTN 200, 250 MS/MSY (VDI) Page 25 - 27 QT/QTN 300-450 MSY (VDI) Page 28 - 30 QT-Ez 8-12 M/MY/MSY Page 31 - 34 QT-Ez 8-12 M/MY/MSY (BMT55) Page 35 - 37 Hyper Quadrex 100, 150 MSY Page 38 - 41 Hyper Quadrex 200, 250 MSY Page 42 - 45 Integrex i-250, 350, 450H ST Page 46 - 46 Integrex i-250, 350, 450H ST (VDI) Page 47 - 49 Reduction sleeves Page 50 - 51 Collets Page 52 - 54 EC = External coolant supply HP-IC = High pressure internal coolant supply through cutting tool IC 80 bar = Internal and external coolant supply Max. coolant pressure = 80 bar IC 30 bar = Internal and external coolant supply Max. coolant pressure = 30 bar Only use filtered coolant fluid (max. particle size = 50 µm) Do not run without coolant Do not use for machining abrasive materials such as cast iron, etc. © WTO Werkzeug-Einrichtungen GmbH * Subject to change without notice * www.wto-tools.com 3
