Solid Carbide Drills Solid Carbide Drills DAN5 - 5×D (with Straight Flute) 㹪䚷㜃汣䧻幹▗捠⪥⍆䢃⎒昌搇⎏ P M K N S H Product Specs 虉5×D Cutting depth 虉130° Tip Angle 虉External Coolant 虉UNIX Coating ΰ β β 虉Tolerance h7 虉For Cast Iron, Aluminum and Copper. Unit:mm Order No. D L1 L Ds Order No. D L1 L Ds 宑庋佷䩋 宑庋佷䩋 DAN504000501 4.00 36 100 4 DAN504500501 4.50 36 100 6 DAN505000501 5.00 44 100 6 DAN505500501 5.50 44 100 6 DAN506000501 6.00 44 100 6 DAN506500501 6.50 53 100 8 DAN507000501 7.00 53 100 8 DAN507500501 7.50 53 100 8 DAN508000501 8.00 53 100 8 DAN508500501 8.50 61 107 10 DAN509000501 9.00 61 107 10 DAN509500501 9.50 61 107 10 DAN510000501 10.00 61 107 10 DAN512000501 12.00 71 150 12 DAN514000501 14.00 77 150 14 DAN516000501 16.00 83 150 16 SB033
