Solid Carbide Drills Solid Carbide Drills DLN - 3×D (for Mini hole) ⶞ⳣ䚷㜃汣䧻幹▗捠⪥⍆昌 P M K N S H Product Specs 虉3×D Cutting depth 虉Reinforced Shank 虉130° Tip Angle 虉External Coolant β ΰ β 虉UNIX Coating 虉Tolerance h8 虉NX Design 虉For Alloy Steel and Cast Iron. Unit:mm Order No. D L1 L Ds Order No. D L1 L Ds 宑庋佷䩋 宑庋佷䩋 DLN00200301 0.20 1.5 38 3 DLN00300301 0.30 2 38 3 DLN00400301 0.40 3 38 3 DLN00500301 0.50 3 38 3 DLN00600301 0.60 3 38 3 DLN00700301 0.70 3 38 3 DLN00800301 0.80 4 38 3 DLN00900301 0.90 4 38 3 DLN01000301 1.00 4 38 3 DLN01100301 1.10 6 38 3 DLN01200301 1.20 6 38 3 DLN01300301 1.30 6 38 3 DLN01400301 1.40 6 38 3 DLN01500301 1.50 6 38 3 DLN01600301 1.60 8 38 3 DLN01700301 1.70 8 38 3 DLN01800301 1.80 8 38 3 DLN01900301 1.90 8 38 3 DLN02000301 2.00 8 38 3 DLN02100301 2.10 8 38 3 DLN02200301 2.20 8 38 3 DLN02300301 2.30 8 38 3 DLN02400301 2.40 8 38 3 DLN02500301 2.50 8 38 3 DLN02600301 2.60 8 38 3 DLN02700301 2.70 8 38 3 DLN02800301 2.80 8 38 3 DLN02900301 2.90 8 38 3 Cutting conditions ( ⎖⏙㨬₅㜇㙩姷 ) : Page SB060 SB021
