Solid Carbide Endmills Recommended Cutting Conditions ら峿⎖⏙╒㜇 Table 032 G550 Seires EPSLC4, EPSMC4, EPSNC4 H600 Seires EHSLC4, EHSMC4, EHSNC4 Material CARBON STEEL / ALLOY STEEL ALLOY STEEL / TOOL STEEL PREHARDENED STEEL ⽴₅㣟㜨 䩂亯撋 0 ▗捠撋 ▗捠撋 0 ⽴⌆撋SCM, SKT, SKD 屎幹撋NAK80 CENA1 Hardness 䧻〵 HB180~250 HRC25~35 HRC35~45 VC 佩憮〵 102 (m/min) 80 (m/min) 67 (m/min) Dia ) ⎒ㄠ * RPM 惘憮 Feed (mm/min)懁仵 ap(mm) ae RPM Feed (mm/min) ap(mm)惘憮懁仵(mm)ae RPM Feed (mm/min) ap(mm)惘憮懁仵(mm)ae(mm) 3mm 10800 647 3 0.15 8500 510 3 0.15 7128 427 3 0.15 4mm 8118 649 4 0.2 4626 513 4 0.2 5346 427 4 0.2 6mm 5414 756 6 0.3 4284 600 6 0.3 3570 500 6 0.3 8mm 4054 568 8 0.4 3210 450 8 0.4 2670 340 8 0.4 10mm 3248 389 10 0.5 2568 307 10 0.5 2138 255 10 0.5 12mm 2700 323 12 0.6 2142 256 12 0.6 1785 214 12 0.6 Material HARDENED STEEL STAINLESS STEEL CAST IRON ⽴₅㣟㜨 㽻䇺撋SKD61, SKD11 ᾜ斌撋SUS304 316 旓旄FC / FCD Hardness 䧻〵 HRC 40~55) VC 佩憮〵 40 (m/min) 67 (m/min) 102 (m/min) Dia ) ⎒ㄠ * RPM 惘憮 Feed (mm/min)懁仵 ap(mm) ae RPM Feed (mm/min) ap(mm)惘憮懁仵(mm)ae RPM Feed (mm/min) ap(mm)惘憮懁仵(mm)ae(mm) 3mm 4330 260 3 0.15 7128 427 3 0.15 10800 647 3 0.15 4mm 3247 260 4 0.2 5346 427 4 0.2 8118 649 4 0.2 6mm 2165 302 6 0.3 3570 500 6 0.3 5414 756 6 0.3 8mm 1624 226 8 0.4 2670 340 8 0.4 4054 568 8 0.4 10mm 1298 155 10 0.5 2138 255 10 0.5 3248 389 10 0.5 12mm 1082 129 12 0.6 1785 214 12 0.6 2700 323 12 0.6 ʰ H600 Series, vc, rpm and feed increase 20% 1.Use as highly rigid and accurate machine as possible. 2.If the rpm available is lower than the recommend condition, please reduce the feed rate to the same ratio. 3.Use long shank type please reduce the rpm and feed rate. 4.The Feed and RPM may be changed depending on the M/C conditions ,lubricating and cooling system. 2/ 䡰╾劌䚷汧⏪ㆶҷ汧乍㯮〙Ҹ 3/ 㯮〙惘憮ᾜ彂㟑虇屚ⶖ懁仵ҷ惘憮▛㵣ℚᾚ屎Ҹ 4/ 朆㥓⤚㎥⇞㚉懝⪶㟑屚嬥㉔㹐ᾚ屎惘憮ҷ懁仵Ҹ 5/ ⁴ᾙ㜇㙩䉉ら峿⇋虇懸䜅䠓㨬₅⁜榗嬥㯮╿䑏㹐ҷ⫍㹊⌆♐幹ҷ䃳䁠⍆┊亊伀ʫ䳘㛈崙Ҹ SA224
