Exchangeable Endmill Head Winmaster - Corner Radius Head - 4F 䧻幹▗捠╾㢎㕪ゞ搠⎏榼 .!⢢烊⎏ .!4!⎒ Work Material Carbon Steel Alloy Steel(S45C, S55C))SKSCM)Pre-Hardened Steel / Hardened Steel~ HRC 40~ HRC 45~ HRC 55Stainless Steel)SUS304, 316)Cast Iron ΰ α α α α ΰ α Order No. Dia. Radius CL ND M Flutes 宑庋佷䩋 (d) (R) (L1) (D) (M) (F) EHCWH EHCWH410005S 10 0.5R 10 6.5 M6 4 EHCWH410010S 10 1.0R 10 6.5 M6 4 EHCWH412005S 12 0.5R 12 6.5 M6 4 EHCWH412010S 12 1.0R 12 6.5 M6 4 EHCWH412020S 12 2.0R 12 6.5 M6 4 EHCWH412030S 12 3.0R 12 6.5 M6 4 EHCWH416010S 16 1.0R 16 8.5 M8 4 EHCWH416020S 16 2.0R 16 8.5 M8 4 d R EHCWH416030S 16 3.0R 16 8.5 M8 4 EHCWH420010S 20 1.0R 20 10.5 M10 4 EHCWH420020S 20 2.0R 20 10.5 M10 4 L1 EHCWH420030S 20 3.0R 20 10.5 M10 4 M D Cutting conditions) ら峿⎖⏙╒㜇姷 * : Page B110 Ød Tolerance All 0 ~ -0.04 R ± 0.02 IA106
