Каталог Widia инструментальная оснастка - страница 695
Навигация
Каталог Widia достижения 2021
Брошюра Widia решения для аэрокосмической промышленности
Брошюра Widia техническое руководство
Каталог Widia токарный инструмент 2020
Каталог Widia цельные концевые фрезы
Каталог Widia техническое руководство по разверткам
Tap Chucks RC Tension and Compression Solid
adapter size
RC-BT Form A
tap size adapter
| order number | catalog number | size | mm | in | D1 D2 | L1 | tension | compression | kg | ||||
| 1778908 | BT50RC1075M | 1 | M1 - M14 | #0 - 9/16 | 19 36 | 73 | 7,5 | 7,5 | 3,10 | ||||
| 1127889 | BT50RC2102M | 2 | M5 - M24 | 5/16 - 7/8 | 31 53 102 | 12,5 | 12,5 | 3,90 | |||||
| 1135816 | BT50RC3141M | 3 | M14 - M27 | 13/16 - 1 3/8 | 48 78 141 | 20,0 | 20,0 | 4,70 |
NOTE: Quick-change tap adapters are available and must be ordered separately; see page I76. For retention knobs, see page J33.
adapter size
STRC-BT Form A
| order number | catalog number | adapter size | tap mm | size in | D1 | D2 | L1 | kg |
| 1778974 | BT50STRC1074M | 1 | M1 - M14 | #0 - 9/16 | 19 | 36 | 74 | 3,80 |
| 1778975 | BT50STRC2089M | 2 | M5 - M24 | 5/16 - 7/8 | 31 | 53 | 89 | 4,00 |
NOTE: Quick-change tap adapters are available and must be ordered separately; see page I76. For retention knobs, see page J33.
