Solid End Milling Solid End Milling VariMill II™ ER length of cut order catalogue D1 D Ap1 max L Rε number Adaptor Style number number grade (mm) (mm) (mm) (mm) (mm) of flutes Machine Side Series 577E • VariMill II™ ER • Victory™ Grades 5599176 577E12015W WS15PE 12,0 12 26,00 83 0,75 5 Weldon 5599177 577E16006V WS15PE 16,0 16 32,00 92 — 5 Safe-Lock 5599178 577E16016V WS15PE 16,0 16 32,00 92 0,75 5 Safe-Lock 5599179 577E16016W WS15PE 16,0 16 32,00 92 0,75 5 Weldon 5599180 577E20007V WS15PE 20,0 20 38,00 104 — 5 Safe-Lock 5599181 577E20017V WS15PE 20,0 20 38,00 104 0,75 5 Safe-Lock 5599182 577E20017W WS15PE 20,0 20 38,00 104 0,75 5 Weldon length of cut order catalogue D1 D D3 Ap1 max L3 L Rε number Adaptor Style number number grade (mm) (mm) (mm) (mm) (mm) (mm) (mm) of flutes Machine Side Series 57NE • VariMill II ER • With Neck • Victory Grades 5599122 57NE10004T WS15PE 10,0 10 9,4 22,00 30,00 76 — 5 Straight-Cylindrical 5599123 57NE10024T WS15PE 10,0 10 9,4 22,00 30,00 76 0,50 5 Straight-Cylindrical 5599124 57NE10024W WS15PE 10,0 10 9,4 22,00 30,00 76 0,50 5 Weldon 5599125 57NE10034T WS15PE 10,0 10 9,4 22,00 30,00 76 1,00 5 Straight-Cylindrical 5599126 57NE10034W WS15PE 10,0 10 9,4 22,00 30,00 76 1,00 5 Weldon 5599127 57NE10054T WS15PE 10,0 10 9,4 22,00 30,00 76 2,00 5 Straight-Cylindrical 5599128 57NE10054W WS15PE 10,0 10 9,4 22,00 30,00 76 2,00 5 Weldon 5599129 57NE12005V WS15PE 12,0 12 11,28 26,00 36,00 83 — 5 Safe-Lock 5599130 57NE12025V WS15PE 12,0 12 11,28 26,00 36,00 83 0,50 5 Safe-Lock 5599131 57NE12025W WS15PE 12,0 12 11,28 26,00 36,00 83 0,50 5 Weldon 5599132 57NE12035V WS15PE 12,0 12 11,28 26,00 36,00 83 1,00 5 Safe-Lock 5599133 57NE12035W WS15PE 12,0 12 11,28 26,00 36,00 83 1,00 5 Weldon 5599134 57NE12055V WS15PE 12,0 12 11,28 26,00 36,00 83 2,00 5 Safe-Lock 5599135 57NE12055W WS15PE 12,0 12 11,28 26,00 36,00 83 2,00 5 Weldon 5599136 57NE16006V WS15PE 16,0 16 15,04 32,00 48,00 100 — 5 Safe-Lock 5599137 57NE16026V WS15PE 16,0 16 15,04 32,00 48,00 100 0,50 5 Safe-Lock 5599138 57NE16026W WS15PE 16,0 16 15,04 32,00 48,00 100 0,50 5 Weldon 5599139 57NE16036V WS15PE 16,0 16 15,04 32,00 48,00 100 1,00 5 Safe-Lock 5599140 57NE16036W WS15PE 16,0 16 15,04 32,00 48,00 100 1,00 5 Weldon 5599141 57NE16056V WS15PE 16,0 16 15,04 32,00 48,00 100 2,00 5 Safe-Lock 5599142 57NE16056W WS15PE 16,0 16 15,04 32,00 48,00 100 2,00 5 Weldon 5599143 57NE20007V WS15PE 20,0 20 18,8 38,00 60,00 115 — 5 Safe-Lock 5599145 57NE20027W WS15PE 20,0 20 18,8 38,00 60,00 115 0,50 5 Weldon 5599146 57NE20037V WS15PE 20,0 20 18,8 38,00 60,00 115 1,00 5 Safe-Lock 5599148 57NE20057V WS15PE 20,0 20 18,8 38,00 60,00 115 2,00 5 Safe-Lock 5599160 57NE20087V WS15PE 20,0 20 18,8 38,00 60,00 115 4,00 5 Safe-Lock 5599161 57NE20087W WS15PE 20,0 20 18,8 38,00 60,00 115 4,00 5 Weldon 5599165 57NE25038V WS15PE 25,0 25 23,50 45,00 75,00 135 1,00 5 Safe-Lock widia.com 83
