GEAR SOLUTIONS FOR SMALL MODULE

Special Solutions with TungMeister

Blank:

Diameter: 17,0 mm to 35,0 mm
Cutting width: 1,9 mm to 16 mm
Cutting depth: to 6 mm
Module sizes: module 0,8 - 3,5

Example:

TungMeister 18Z25002TRRA061 A35HP Gear finish mill module 2; No. of gear teeth = 23

Blank Cutting depth: to 6 mm

Cutting width: 10 mm to 25 mm Diameter: 8 mm to 25 mm Module sizes: module 2.5 to 12

Example:

Gear finish end mill module 12; TungMeister 47Z04037TURA10 AH730 No. of gear teeth = 128
