Milling Cutter A\
4'


ASPV Type Endmill ASPV Type Milling Modular

z1
Q
fi
L1
C
IV1
- E
Notch width

_
O
/,
in ;
LI
L
Ls
Q
> -s
3 A
B


mm
Dimension(mm) Dimension(mm)
Designation No.of Inserts Arbor Designation No.of Inserts
D1 LI L LS d D1 D LI d M D2 A B C E
ASPV 06 R 1616-100L - 2 T 2 16 30 100 70 16 14.5 S 0.12 ASPV 06 R 016 - M08 - 2T 2 16 25 8.5 M8 12.8 5.5 17 8 10 0.03
2020-100 L - 3 T 3 20 30 100 70 20 18.0 S 0.21 017-M08- 2 T 2 17 25 8.5 M8 14.5 5.5 17 8 10 0.03
2020-150L - 3 T 3 20 30 150 120 20 18.0 S 0.34 020 - M10- 3T 3 20 30 10.5 M10 17.8 5.5 19 10 15 0.05
2525 -150L -4T 4 25 40 150 110 25 23.0 S 0.35 021-M10- 3T 3 21 30 10.5 M10 17.8 5.5 19 10 15 0.05
2525 - 200L -4T 4 25 40 200 160 25 23.0 S 0.59 025 - M12- 4T 4 25 35 12.5 M12 20.8 5.5 22 10 17 0.09
3025 -150L -4T 4 30 50 150 100 25 28.0 S 0.38 026- M12- 4T 4 26 35 12.5 M12 20.8 5.5 22 10 17 0.10
3025 - 200L -4T 4 30 50 200 150 25 28.0 S 0.62 032-M16- 5T 5 32 40 17.0 M16 28.8 6.0 23 12 22 0.19
3232 -150L - 5 T 5 32 50 150 100 32 30.0 S 0.60 035-M16- 5T 5 35 40 17.0 M16 28.8 6.0 23 12 22 0.21
3232 - 200L - 5 T 5 32 50 200 150 32 30.0 S 1.00 042-M16- 6T 6 42 40 17.0 M16 28.8 6.0 23 12 22 0.25
3532-150L - 5 T 5 35 50 150 100 32 31.0 S 0.70
3532 - 200L - 5 T 5 35 50 200 150 32 31.0 S 1.10
4032 -150 L - 6T 6 40 50 150 100 32 31.0 S 0.80
4032 - 200L - 6T 6 40 50 200 150 32 31.0 S 1.20


511 512
