A\
FXD 5xD/6xD/8xD/10xD Parts
Standard Type
o
eo : rS)
1 Q
TYPE
L1 Ls
L
Insert screw Wrench
Shank FXD- 250 L0560SSTX 2.2 - 3.0P TPF - 06
DS LS B
-
FXD- 250 350 L0655SSTX 2.5 - 3.6P TPF -08
S3 2 32 60 PT- 1 /4
FXD 360 - 440
- L0960SSTX 3.5 - 5.3 P TPF -15
mm
FXD -450 - 500 L1060SSTX4.0- 5.7P TPF -15
5D 6D 8D 10D
Designation D Insert Pilot Drill
LI L LI L LI L LI L
FXD-400 -40-D 40 200 286 240 326 320 406 400 486
FXD-410-40-D 41 205 291 246 332 328 414 410 496
FXD-420-40-D 42 210 296 252 338 336 422 420 506 SPMG090408
Pilot Drill
FXD -430-40-D 43 215 301 258 344 344 430 430 516
FXD-440-40-D 44 220 306 264 350 352 438 440 526
PLD-1035 - H
FXD-450-40-D 45 225 311 270 356 360 446 450 536
FXD-460-40-D 46 230 316 276 362 368 454 460 546
FXD-470-40-D 47 235 321 282 368 376 462 470 556
1
as
FXD-480 -40-D 48 240 326 288 374 384 470 480 566 SPMG110408
FXD-490-40-D 49 245 331 294 380 392 478 490 576 o
FXD - 500 -40 - D 50 250 336 300 386 400 486 500 586

FXD Drill is capable of working laminated boards. Please reduce the feed rate by 30% ~ 50% when performing
t L
penetration work .

mm

Coated Dimension(mm)
Designation Oil- hole
TiN TiALN D L
PLD - 0620 6 20 NO
PLD - 0835 8 35 YES
PLD -1035 - H 10 35 YES


725 726
