A\
VLT 5xD/6.5xD/8xD Parts
Dual insert cartridge type
PT-1 /4

TYPE
LI LS
L .

Insert screw Wrench
Shank DS LS -
VLT - 250 300 L0655SSTX 2.5 - 3.6 P TPF - 08

VLT 310 - 400
- L0750SSTX 3.0-4.0 P TPF -08
S40 40 70
VLT 410 - 500
- L0960SSTX 3.5 - 5.3 P TPF -15

VLT- 510 - 590 L1160SSTX4.0- 5.7 P TPF - 15
mm VLT- 6065 - 7075 L0750SSTX 3.0-4.0 P TPF -08

5D 6D 8D 10D VLT-7580 L0960SSTX 3.5 - 5.3P TPF -15
Designation D Insert Pilot Drill
LI L LI L LI L LI L
VLT- 6065 -40-D 60- 65 325 430 390 495 520 625 650 755
Pilot Drill
VLT- 6570-40-D 65 -70 350 455 420 525 560 665 700 805 WCMX050308 PLD -1238- H
VLT-7075 -40-D 70-75 375 480 450 555 600 705 750 855
VLT-7580-40-D 75 - 80 400 505 485 585 640 745 800 905 WCMX06T308 PLD -1645 -H
I
Ex) machining hole 70.5mm * 6D - > VLT-7075 -40- 6D
d——
06O ~ 08O : Cut the outer cartridge and setting.(adjust 5 mm)
L
mm

Coated Dimension(mm)
Designation Oil -hole
TiN TiALN D L
PLD- 0630 6 30 NO
PLD- 0835 8 35 YES
PLD-1035 - H 10 35 YES
PLD-1238 - H 12 39 YES
PLD-1645 H - 16 45 YES


721 722
