Slanted Shoulder & Chamfer A\

45° AP Type Chamfer Cutter AP Type Chamfer Cutter

1
d
1


mm
Dimension(mm) Dimension(mm)
No.of No.of
Designation No.of Inserts Designation
flute Inserts
D d LI L Chamfering Range D da d H ap a
B 45 ° AP11 C16Tl-120ap4-13 1 13 16 30 120 4-13 B 15 ° AP16- D 3593 - A 27- Z0306 3 6 93 35 27 50 8.0
AP16 C16Tl-120ap8-21 1 21 16 35 120 8-21 B 30° AP16- D 3587- A27-Z0306 3 6 87 35 27 50 15.0
AP16 C 20Tl-120ap8-21 1 21 20 35 120 8-21 B 45 ° AP16- D 3577 - A 27- Z0306 3 6 77 35 27 50 21.5
AP16 C 20T2 -120apl8 - 32 2 32 20 35 120 18- 32 B60° AP16- D 3565 - A 22- Z0306 3 6 65 35 22 50 26.5
AP16 C 25T2 -120ap 25 -40 2 40 25 35 120 25 -40 B75 ° AP16- D 3550- A 22-Z0306 3 6 50 35 22 50 29.5


Parts


TYPE
Insert screw Wrench
B - AP11 L0655 SSTX 2.5 - 3.6 P TPF - 08
B- AP16 L0960SSTX4.0- 5.7 P TPF -15


589 590
