Profiling A\
ARPF Type Ball Precision Modular KM Type Shell Mill

D2
W

X
Li (A
"
D


mm mm
Dimension(mm) Spare parts Dimension(mm)
Designation No.of Inserts Designation No.of Inserts
D LI d M Screw wrench D D2 d W T H ap Arbor
ARPF 012 -M06 1 12 20 6.5 M6 TS50100 B T20 KM 12 050- 22 - 04T 4 50 64 22 10.4 6.3 50 6.0 A
016-M08 1 16 28 8.5 M8 TS50134B T20 063 - 22 - 04T 4 63 77 22 10.4 6.3 50 6.0 A
020-M10 1 20 30 10.5 M10 TS60167 B T25 080- 27- 05 T 5 80 94 27 12.4 7.0 50 6.0 B
025 -M12 1 25 35 12.5 M12 TS60218 B T 30 100- 32-05 T 5 100 114 32 14.4 8.0 50 6.0 B
030-M16 1 30 40 17.0 M16 TS80250 B T30 125 -40- 06T 6 125 139 40 16.4 9.0 63 6.0 B
160-40- 06T 6 160 174 40 16.4 9.0 63 6.0 C
200- 60- 08T 8 200 210 60 25.7 14.0 63 6.0 C
250- 60-10T 10 250 260 60 25.7 14.0 63 6.0 C


BNM Type Ball Precision Modular
Parts
D


TYPE
mm
Insert screw Wrench
Dimension(mm) Spare parts
Designation No.of Inserts KM12 L1160SSTX 5.0- 7.0 P FF - TPF15
D LI d M Screw wrench
RNM 012 -M06 1 12 20 6.5 M6 TS35095 B T15
016-M08 1 16 28 8.5 M8 TS40132B T15
020-M10 1 20 30 10.5 M10 TS50163 B T20
025 -M12 1 25 35 12.5 M 12 TS60202B T25
030- M16 1 30 40 17.0 M16 TS80252B T 30
