Profiling A\
0


WGR Type Ball Precision Endmill WGR Type Ball Precision Modular


Q
ea 73

w L1
L
R
L1


mm
Dimension(mm) Spare parts Dimension(mm) Spare parts
Designation No.of Inserts Adapter Designation No.of Inserts
D d LI L R Screw wrench D LI d M D2 Screw wrench R
WGR 04 R -C08 -110 L 1 8 8 25 110 4 TS30070B T -8 S WGR 008-M04 1 8 16 4.5 M4 9.2 TS 30070 B T -8 4
04R-C10-110 L 1 8 10 25 110 4 TS30070B T- 8 S 010-M05 1 10 20 5.5 M5 9.2 TS40087B T15 5
04R -C12 -110 L 1 8 12 55 140 4 TS30070B T -8 S 012 -M06 1 12 20 6.5 M6 10.0 TS 50094B T20 6
05 R-C10-130 L 1 10 10 30 130 5 TS40085 B T-15 S 016-M08 1 16 28 8.5 M8 13.0 TS 50128B T20 8
05 R -C12 -160L 1 10 12 30 160 5 TS40087 B T -15 S 020-M10 1 20 30 10.5 M10 18.0 TS 20129B T20 10
06 R -C12 -130L 1 12 12 32 130 6 TS50094B T - 20 S 025 -M12 1 25 35 12.5 M12 21.0 TS60210B T- 25 12.5
06 R - C16-160L 1 12 16 58.5 160 6 TS50094B T- 20 S 030-M16 1 30 40 17.0 M16 29.0 TS80247 B T - 30 15
08 R -C16- 160 L 1 16 16 65 160 8 TS50128 B T - 20 S
08 R - C20-200 L 1 16 20 65 200 8 TS50128 B T- 20 S
10 R -C20- 160 L 1 20 20 45 160 10 TS20129 B T- 20 S
10 R -C20-200 L 1 20 20 76 200 10 TS50129 B T- 20 S
10 R-C25 -250 L 1 20 25 120 250 10 TS50129B T - 20 S
12.5 R -C25 -160L 1 25 25 45 160 12.5 TS60210B T- 25 S
12.5 R -C25 - 200L 1 25 25 76 200 12.5 TS60210B T- 25 S
12.5 R -C 32 - 200L 1 25 32 98 200 12.5 TS60210B T-25 S
12.5 R -C 32 - 250L 1 25 32 120 250 12.5 TS60210B T-25 S
15 R-C 32 -200 L 1 30 32 80 200 15 TS80247 B T-30 S
15 R-C40-250 L 1 30 40 121 250 15 TS80247 B T - 30 S
