EndmillsSquareRadiusBallnoseMulti-PurposeGeneral-purposeHighEfficiencyHardene dSteelRoughingNon-ferrousMetalCFRPCoatedUncoated Stock ±0.01 DC DMM h5 GSX MILL 4 Flute Radius Endmills Anti-vibration Type GSXVL 4000S-R-2.5D Type General CarbonSteelSteelAlloySteelPre-hardenedSteelTemperedSteel/Die SteelHardenedSteel45 to 55HRCHardenedSteel55 to 60HRCStainlessSteelTi Alloy /Heat ResistantAlloyCast Iron Corner Flutes Coat Helix Angle Applicable Products Side Milling Grooving Groove Finishing Face Milling Helical Milling Ramping Profiling Fig 1 APMX RE±0.02 LF I Body ( Product) Dimensions (mm) Cat. No. Dia.DC Radius Cutting Edge Length Overall LengthREAPMXLF Shank Dia.DMM Fig GSXVL 4120S-R05-2.5D ● 12.0 0.5 30.0 90 12 1 GSXVL 4120S-R10-2.5D ● 12.0 1.0 30.0 90 12 1 GSXVL 4120S-R15-2.5D ● 12.0 1.5 30.0 90 12 1 GSXVL 4120S-R20-2.5D ● 12.0 2.0 30.0 90 12 1 GSXVL 4120S-R30-2.5D ● 12.0 3.0 30.0 90 12 1 GSXVL 4160S-R10-2.5D ● 16.0 1.0 40.0 115 16 1 GSXVL 4160S-R15-2.5D ● 16.0 1.5 40.0 115 16 1 GSXVL 4160S-R20-2.5D ● 16.0 2.0 40.0 115 16 1 GSXVL 4160S-R30-2.5D ● 16.0 3.0 40.0 115 16 1 GSXVL 4200S-R10-2.5D ● 20.0 1.0 50.0 125 20 1 GSXVL 4200S-R15-2.5D ● 20.0 1.5 50.0 125 20 1 GSXVL 4200S-R20-2.5D ● 20.0 2.0 50.0 125 20 1 GSXVL 4200S-R30-2.5D ● 20.0 3.0 50.0 125 20 1 GSXVL 4250S-R10-2.5D ● 25.0 1.0 63.0 140 25 1 GSXVL 4250S-R15-2.5D ● 25.0 1.5 63.0 140 25 1 GSXVL 4250S-R20-2.5D ● 25.0 2.0 63.0 140 25 1 GSXVL 4250S-R30-2.5D ● 25.0 3.0 63.0 140 25 1 Grade: ACF20 For the regrinding procedure, please download the details from our website. www.sumitool.com/en/products/ cutting-tools/endmills/gsx.html I108
