Milling CuttersFace MillingShoulde rMillingHigh FeedMulti-PurposeRadiusR / 3DProfilingGroove /T-SlotChamferingNon-ferrousMetalHigh-speedCast Iron StockStock ACZ350 ACZ330 ACZ310 H1 DL1000 DC StockStock 85° DMM h7 9.525 11° SEC-WaveMulti WMM 3000E / EL / ELH / EXLH Type Steel Stainless Steel Cast Iron Non-Ferrous Metal Aluminum Alloy Radial 17° to 19° Rake Angle Axial 7° to 11° Fig 1 APMX LH LS LF H Body (Standard Type / WMM3000E Type)  Dimensions (mm) Milling Cutter Body (Long Type)  Dimensions (mm) Cat. No. Dia. DC Shank DMM Max.DepthofCut APMX Head LH Shank LS Overal Length LF Total No. of Teeth Efective NumberofTeeth Fig Cat. No. Dia. DC Shank DMM Max.DepthofCut APMX Head LH Shank LS Overal Length LF Total No. of Teeth Efective NumberofTeeth Fig WMM 3032E ● 32 32 39 50 100 150 4 1 1 WMM 3032EL ● 32 32 39 90 140 230 4 1 1 WMM 3033E ● 33 32 39 50 100 150 4 1 1 WMM 3033EL ● 33 32 39 50 180 230 4 1 1 WMM 3035E ● 35 32 39 50 100 150 4 1 1 WMM 3035EL ● 35 32 39 50 180 230 4 1 1 WMM 3040E ● 40 32 39 55 105 160 4 1 1 WMM 3040EL ● 40 32 39 55 185 240 4 1 1 WMM 2030E ● 30 25 35 50 100 150 5 1 1 Body (Extra-Long Type / With Coolant Holes) Dimensions (mm) Body (Long Type / With Coolant Holes)  Dimensions (mm)Cat. No.Dia. DC Shank DMM Max.DepthofCut APMX Head LH Shank LS Overal Length LF Total No. of Teeth Efective NumberofTeeth FigCat. No.WMM 3035EXLHDia. DC Shank DMM Max.DepthofCut APMX Head LH Shank LS Overal Length LF Total No. of Teeth Efective NumberofTeeth Fig35323950320370411 WMM 3032ELH ● 32 32 39 90 140 230 4 1 1 WMM 3040EXLH 40 32 39 55 365 420 4 1 1 WMM 3033ELH ● 33 32 39 50 180 230 4 1 1 WMM 3035ELH ● 35 32 39 50 180 230 4 1 1 WMM 3040ELH ● 40 32 39 55 185 240 4 1 1 Insert  Dimensions (mm) Grade Coated Carbide High-speed / Light N Process General-purpose M P K N Roughing Cat. No. Nose RadiusRE Fig APMT 160508PDER ● ● ● Q Q 0.8 1 Fig 1 APMT 160512PDER ● ● ● Q Q 1.2 1 APMT 160516PDER ● ● ● Q Q 1.6 1 APMT 160508PDER-H ● ● ● Q Q 0.8 1 APMT 160512PDER-H ● ● ● Q Q 1.2 1 RE 16 5.56 APMT 160516PDER-H ● ● ● Q Q 1.6 1 APMT 160520PDER-H* ● ● ● Q Q 2.0 1 APMT 160530PDER-H* ● ● ● Q Q 3.0 1 APMT 160540PDER-H* ● ● ● Q Q 4.0 1 APMT 160550PDER-H* ● ● ● Q Q 5.0 1 APMT 160560PDER-H* ● ● ● Q Q 6.0 1 APET 160508PDER-F ● ● ● Q Q 0.8 1 APET 160508PDFR-S Q Q Q ● ● 0.8 1 -H: Strong Edge Type, F: Ground Insert, S: For Aluminum Alloy. * marked inserts require modification of the cutter body. Correct the tool diameter by +0.5mm before use. ■ Recommended Cutting Conditions Blade Diameter ø30 to ø40mm (Not for extra-long type) Parts Applicable Endmill Flat Screw Wrench Anti-seizure Cream WorkISO Hardness Cutting Speed vc (m/min) Feed Rate fz (mm/t) InsertMaterialMin. - Optimum - Max.Min. - Optimum - Max.Grade WMM2000 Type BFTX02506N Nm 1.5 TRD08 SUMI-PWMM3000 TypeBFTX03584Nm3.0TRD15SUMI-P P CarbonSteel180 to 280HB Shoulder Miling 0.05- 0.15 -0.2580- 120 -160Groove Milling0.05- 0.10 -0.15ACZ330Drilling0.05- 0.13 -0.20 M StainlessSteel Q Shoulder Miling 0.05- 0.13 -0.2080- 100 -120Groove Milling0.05- 0.09 -0.12ACZ350Drilling0.05- 0.12 -0.18 Shoulder Miling 0.05- 0.15 -0.25 K Cast Iron 250HB 70- 150 -180 Groove Milling 0.05- 0.10 -0.15 ACZ310 Drilling 0.05- 0.13 -0.20 Shoulder Miling 0.10- 0.15 -0.20 N Aluminum Q 200- 300 -500 Groove Milling 0.05- 0.08 -0.10 DL1000 Alloy Drilling 0.05- 0.08 -0.10 Note The cutting conditions are guidelines. Actual conditions will need to be adjusted according to machine rigidity, work clamp rigidity, depth of cut and other factors. H158 N m Recommended Tightening Torque (N·m)
