Milling CuttersFace MillingShoulde rMillingHigh FeedMulti-PurposeRadiusR / 3DProfilingGroove /T-SlotChamferingNon-ferrousMetalHigh-speedCast Iron MetricMetricMetricInch StockStockStock ACP200 ACP300 ACK200 ACK300 CBDP KDP LF CBDP KDP LF SEC-Metal Slash Mill MSX 08000RS / 12000RS / 14000R(S) Type Steel Stainless Steel Cast Iron Hardened Steel Radial –3° to –8° Rake Angle Axial 8° (08000 Type) (12000 Type) (14000 Type) Fig 1 DCSFMS Fig 2 DCSFMS DCB DCB KWW KWW D2 D1 H D1 DCXDCX Body (MSX08000) Applicable Insert WDMT08 Type  Dimensions (mm) Cat. No. Max. Dia. Boss Height Bore Dia. Keyway Width Keyway Depth Mounting Depth BoltDCXDCSFMSLFDCBKWWKDPCBDPD1BoltD2Numberof Teeth Weight(kg) Fig MSX 08040RS ● 40 37 45 16 8.4 5.6 18 13.5 9 4 0.2 1 Body (MSX12000) Applicable Insert WDMT12 Type  Dimensions (mm) Cat. No. Max. Dia. Boss Height Bore Dia. Keyway Width Keyway Depth Mounting Depth BoltDCXDCSFMSLFDCBKWWKDPCBDPD1BoltD2Numberof Teeth Weight(kg) Fig MSX 12050RS ● 50 47 50 22 10.4 6.3 20 18 11 4 0.3 1 MSX 12063RS ● 63 60 50 22 10.4 6.3 20 18 11 5 0.6 1 Body (MSX14000) Applicable Insert WDMT14 Type  Dimensions (mm) Cat. No. Max. Dia. Boss Height Bore Dia. Keyway Width Keyway Depth Mounting Depth BoltDCXDCSFMSLFDCBKWWKDPCBDPD1BoltD2Numberof Teeth Weight(kg) Fig MSX 14050RS ● 50 47 50 22 10.4 6.3 20 17 11 3 0.3 1 MSX 14063RS ● 63 60 50 22 10.4 6.3 20 18 11 4 0.6 1 MSX 14080RS ● *80 76 63 27 12.4 7.0 25 20 13.5 5 1.4 1 MSX 14100RS ● 100 96 63 32 14.4 8.5 32 44 6 2.2 2 MSX 14080R ● *80 76 63 31.75 12.7 8.0 32 28 17 5 1.3 1 MSX 14100R ● *100 96 63 31.75 12.7 8.0 32 28 17 6 2.4 1 Inserts are sold separately. For securing the ø80mm and ø100mm cutters to the arbors marked with *, use a JIS B1176 hexagonal socket bolt (ø80: M12 x 30 to 35mm, ø100: M16 x 40 to 45mm). Insert  Dimensions (mm) Grade Coated Carbide High-speed / Light K Process General-purpose K Roughing K Fig 1 Applications Cat. No. Inscribed Circle IC Thickness S Nose Radius RE ApplicableCutterFig IC General-purposeWDMT 0804ZDTRWDMT 1205ZDTRWDMT 1406ZDTR●● ● ● 8.5 4.0●●●●125.0●●●●146.02.0 MSX08000R Type 12.0MSX12000R Type12.0MSX14000R Type1 RE S HonedType WDMT 0804ZDTR-HWDMT 1205ZDTR-HWDMT 1406ZDTR-H●●● ●●●●●●●●●8.512144.05.06.0 2.0 MSX08000R Type 12.0MSX12000R Type12.0MSX14000R Type1 Recommended Cutting Conditions H153 Parts Identification Code Applicable Flat Screw Wrench Clamp C-Ring Clamp Screw MSX 08 040 R S Body Nm Cutter Series Insert Cutter Dia. Feed Metric Size Direction Bore MSX08000R Type BFTX0306IP 2.0 TRDR08IP CCH3.5 CR03 BFTX03510IP08 MSX12000R Type BFTX0409IP 3.0 TRDR15IP CCH3.5 CR03 BFTX03510IP15 MSX14000R Type BFTX0511IP 5.0 TRDR20IP CCH4.5 CR03 BFTX04513IP20 H154 N m Recommended Tightening Torque (N·m)
