Inch CBDPACP100 KDP ACP200 ACP300 ACK200 LF ACK300 CBDPEH20Z KDP A30N G10E H1 LFH10E CBDPT250A KDP LF15.87515.875 CBDP25°25° KDP 15.87515.3 32° LF25°25° High-speedCast IronNon-ferrousMetalChamferingGroove /T-SlotR / 3DProfilingRadiusMulti-PurposeHigh FeedShoulderMillingFace MillingMillingCutters SEC-SUMI UFO Mill UFO 5000 Type Steel Stainless Steel Cast Iron Non-Ferrous Metal Aluminum Alloy Exotic Alloy Radial -7° Rake Angle Axial 27° Fig 1 Fig 2 Fig 3 BD Fig 4 BD BD BD DCSFMS DCSFMSø177.8 DCSFMS DCSFMSDCBDCBKWW ø101.6DCB ø18KWWKWW ø101.6DCB ø18 ø22KWW ø13 ø20 DC DCDC DC H Body  Dimensions (mm) Cat. No. Stock Dia.RLDC O.D. BD BossDCSFMS HeightLF Bore Dia. Keyway Width Keyway Depth Mounting Depth Number ofDCBKWWKDPCBDPTeeth Weight(kg) Fig UFO 5080R/L *80 102 60 50 25.4 9.5 6 25 4 2.0 1 UFO 5100R/L ● 100 119 70 50 31.75 12.7 8 32 5 2.8 2 UFO 5125R/L ● 125 143 75 63 38.1 15.9 10 38 6 4.0 2 UFO 5160R/L ● 160 177 100 63 50.8 19.1 11 38 8 6.4 2 UFO 5200R/L ● 200 217 130 63 47.625 25.4 14 35 10 9.2 3 UFO 5250R/L 250 267 130 63 47.625 25.4 14 35 12 14.4 3 UFO 5315R/L 315 332 240 80 47.625 25.4 14 35 14 26.1 4 Inserts are sold separately. For securing the ø80mm cutters to the arbors marked with *, use a JIS B1176 hexagonal socket bolt (M12 x 30 to 35mm). Insert  Dimensions (mm) Grade Coated Carbide Carbide Cermet High-speed / Light P K M Process General-purpose K P K K P Fig 1 Fig. 2 (Grades in ACP/ACK Series) Roughing K 2.2 2.2 Cat. No. Fig 15.875 4.76 15.875 4.76 SFEN 1504AZTN ● ● ● ● 1 SFEN 1504AZTN-S 1 SFEN 1504AZTN-W 1 Fig 3 Fig 4 Wiper Insert SFEN 1504AZFN 1 2.2 SFKN 1504AZTN ● ● ● ● ● 2(3) SFKN 1504AZTN-S 3 SFKN 1504AZTN-W 3 SFKN 1504AZFN ● ● ● 2(3) 15.875 4.76 20 4.76±0.025 UW 15500R ● 4 UW 15500L Q -S: Sharp Edge, -W: Strong Edge. Double Screw Engraved Mark 5SR Insert Clamp Shim Insert Locator Double Screw Clamp Parts Recommended Cutting Conditions ApplicableCutter Locator Insert DoubleClampClampScrewSizeNm Seat Locator WorkISOMaterialHardness Cutting Speed vc (m/min) Feed Rate fz (mm/t)Min. - Optimum - Max. Min. - Optimum - Max.InsertGradeGeneral Steel 180 to 280 HB100- 175 -2500.15- 0.23 -0.30ACP200 UFO 5000RUFO 5000L UFKWR UFTWRUFKWLUFTWL WB7-15 M7 8.0 UF5SR UF5SL UF5KRUF5KL P Mild Steel ≤ 180HB 125- 210 -300 0.15- 0.23 -0.30 ACP200Die Steel200 to 220 HB80- 140 -2000.15- 0.20 -0.25ACP200 T-wrench (TT25) is included as a standard accessory. M Stainless Steel Q 160- 190 -220 0.15- 0.23 -0.30 ACP300 K Cast Iron 250HB 60- 155 -250 0.15- 0.23 -0.30 ACK200 N Non-Ferrous Alloy Q 300- 550 -800 0.15- 0.23 -0.30 H1 Note The cutting conditions above are a guide. Actual conditions will need to be adjusted according to machine rigidity, work clamp rigidity, depth of cut and other factors. N m Recommended Tightening Torque (N·m) H37
