Общий каталог Sumitomo 2019 - 2020 - страница 430

ToolingToolingCartridges WF WF WF DCSFMSDCSFMSDCSFMS Polygonal Taper Shank SumiPolygon 95° Internal Internal Boring Coolant Lever Lock PCLN Fig 1 Min. BoreDia. (DMIN) Bottom Facing 95° Insert (Representative example) Applicable Insert Cat. No. Ref. Page LF CN□□0903○○ B20 CNMG090308N-GU Figure shows right hand (R) tool. G Holder Parts  Dimensions (mm) Stock Min. Bore CuttingDia.Edge Overhang Mounting LeverPin SetScrew Shim Shim Set Screw Wrench Cat. No. Fig R L DMIN WF LF DCSFMS PSC40 PCLN R/L 17080-09 ●● 32 17 80 40 1 LCL3 LCS3 LSC32 LSP3 LH025 Internal Internal Boring 93˚ Coolant Double Clamp DDUN Fig 1 Min. BoreDia. (DMIN) Profiling 93° Insert (Representative example) LF Applicable Insert Cat. No. Ref. Page DN□□1504○○ B32on DNMG150408N-GE Figure shows right hand (R) tool. Holder Parts Dimensions (mm) Cat. No. Stock Min.BoreDia.Cutting Edge Overhang MountingFig Clamp Set Shim Shim Shim For Upper For LowerScrewWrench Surface Wrench Surface Wrench R L DMIN WF LF DCSFMS Nm PSC40 DDUN R/L 20050-15 ●● 40 20 50 40 1 PSC40 DDUN R/L 20070-15 ●● 40 20 70 40 1 SCP-2 5.0 DNS1504B BFTX0409N TRX15(*) LH040 LH025 PSC40 DDUN R/L 27090-15 ●● 54 27 90 40 1 *Wrench for shim is sold separately from the main unit. Clamp Set Parts E70 Internal Internal Boring 93˚ Coolant Lever Lock PDUN Fig 1 Min. BoreDia. (DMIN) Profiling 93° Insert (Representative example) LF Applicable Insert Cat. No. Ref. Page DN□□1104○○ B31on DNMG150408N-GE Figure shows right hand (R) tool. Holder Parts Dimensions (mm) Stock Min. Bore CuttingDia.Edge Overhang Mounting LeverPin SetScrew Shim Shim Set Screw Wrench Cat. No. Fig R L DMIN WF LF DCSFMS PSC40 PDUN R/L 17080-11 ●● 32 17 80 40 1 LCL3 LCS3 LSD317 LSP3 LH025 G14 N m Recommended Tightening Torque (N·m) ● mark: Standard stocked item (new product/expanded item)
