FRACTIONAL Carbon Composite Ap Series Ae Ae DC • in 20 Vc Fractional Ae x DC Ap x DC (sfm) 1/4 5/16 3/8 1/2 RPM 6112 4890 4075 3056 Slot 400 1 ≤1 Fr 0.0049 0.0094 0.0135 0.0180 (320-480) Feed (ipm) 30 46 55 55 RPM 7640 6112 5093 3820 CFRP, AFRP Profile 500 Fr 0.0049 0.0094 0.0135 0.0180 (CARBON FIBER, ≤ 0.5 ≤ 1.5 (400-600) ARAMID FIBER) Feed (ipm) 38 58 69 69 RPM 12606 10085 8404 6303 HSM 825 ≤ 0.05 ≤2 Fr 0.0111 0.0215 0.0309 0.0413 (660-990) Feed (ipm) 140 217 260 260 RPM 4890 3912 3260 2445 Slot 320 1 ≤1 Fr 0.0049 0.0095 0.0135 0.0180 (256-384) Feed (ipm) 24 37 44 44 RPM 6112 4890 4075 3056 Profile GFRP 400 ≤ 0.5 ≤ 1.5 Fr 0.0049 0.0095 0.0135 0.0180 (FIBERGLASS) (320-480) Feed (ipm) 30 46 55 55 RPM 10085 8068 6723 5042 HSM 660 ≤ 0.05 ≤2 Fr 0.0110 0.0214 0.0311 0.0414 (528-792) Feed (ipm) 111 173 209 209 N RPM 7334 5868 4890 3667 Slot 480 1 ≤1 Fr 0.0064 0.0124 0.0180 0.0240 (384-576) Feed (ipm) 47 73 88 88 RPM 9168 7334 6112 4584 Profile 600 CARBON, GRAPHITE ≤ 0.5 ≤ 1.5 Fr 0.0064 0.0124 0.0180 0.0240 (480-720) Feed (ipm) 59 91 110 110 RPM 15127 12102 10085 7564 HSM 990 ≤ 0.05 ≤2 Fr 0.0147 0.0287 0.0412 0.0549 (792-1188) Feed (ipm) 223 347 415 415 RPM 10161 8129 6774 5081 Slot 665 1 ≤1 Fr 0.0077 0.0150 0.0217 0.0241 (640-690) Feed (ipm) 78 122 147 147 RPM 15280 12224 10187 7640 Profile 1000 PLASTICS ≤ 0.5 ≤ 1.5 Fr 0.0077 0.0150 0.0217 0.0241 (800-1200) Feed (ipm) 118 183 221 184 RPM 25212 20170 16808 12606 HSM 1650 ≤ 0.05 ≤2 Fr 0.0147 0.0287 0.0413 0.0551 (1320-1980) Feed (ipm) 370 579 694 694 HSM (high speed machining) finish cuts typically required reduced feed and cutting depths rpm = Vc x 3.82 / DC rates shown are for use without coolant; rates may be increased with coolant ipm = Fr x rpm dust collection is vital when machining dry adjust parameters based on resin type and fiber structure diamond coating will increase tool life in graphite and composite materials reduce speed when overheating causes melting or damage to resin refer to the SGS Tool Wizard® for complete technical information reduce feed if delamination or fraying occur   (www.kyocera-sgstool.com) 340 ROUTERS ROUTERS www.kyocera-sgstool.com
