FRACTIONAL & METRIC Ski-Carb 45° POS 2 LF APMX DC DCON 44 FRACTIONAL SERIES TOLERANCES (inch) inch EDP NO. • Polished ski land 1/4–3/8 DIAMETER CUTTING LENGTH OVERALL SHANK UNCOATED Ti-NAMITE-B UNCOATED Ti-NAMITE-B with primary and DIAMETER OF CUT LENGTH DIAMETER W/FLAT (TiB2) (TiB2) secondary flute wall DC = +0.0000/–0.00035 DC APMX LF DCON W/FLAT design minimizes DCON = h 6 chip interference by 1/4 3/4 2-7/16 3/8 34501 34502 32033 32053 directing chips away 1/2–5/8 DIAMETER 1/4 1-1/4 3-1/16 3/8 34503 34504 32034 32054 from secondary flute DC = +0.0000/–0.00043 1/4 1-3/4 3-9/16 3/8 34505 34506 32035 32055 • Circular land allows DCON = h 6 for increased control 5/16 1-3/8 3-1/8 3/8 34507 34508 32036 32056 at various speed and 3/4–1 DIAMETER feed rates ultimately 3/8 3/4 2-1/2 3/8 34509 34510 32037 32057 DC = +0.0000/–0.00051 reducing chatter DCON = h 6 3/8 1-1/2 3-1/4 3/8 34511 34512 32038 32058 • Recommended for 3/8 2-1/2 4-1/4 3/8 34513 34514 32039 32059 materials ≤ 150 Bhn (≤ 7 HRc) NON-FERROUS 1/2 1-1/4 3-1/4 1/2 34515 34516 32040 32060 PLASTICS/COMPOSITES 1/2 2 4 1/2 34517 34518 32041 32061 1/2 3 5 1/2 34519 34520 32042 32062 For patent 5/8 1-5/8 3-3/4 5/8 34521 34522 32043 32063 information visit www.ksptpatents.com 5/8 2-1/2 4-5/8 5/8 34523 34524 32044 32064 3/4 1-5/8 3-7/8 3/4 34525 34526 32045 32065 3/4 3 5-1/4 3/4 34527 34528 32046 32066 3/4 4 6-1/4 3/4 34529 34530 32047 32067 1 2 4-1/2 1 34531 34532 32048 32068 1 4 6-1/2 1 34533 34534 32049 32069 Contact your KSPT Sales Representative for more information on Corner Radius options. LF APMX TOLERANCES (mm) ≤3 DIAMETER DC DCON 44M METRIC SERIES DC = +0,000/–0,006 DCON = h 6 mm EDP NO. • Polished ski land CUTTING LENGTH OVERALL SHANK UNCOATED UNCOATED Ti-NAMITE-B Ti-NAMITE-B with primary and >3–6 DIAMETER DIAMETER OF CUT LENGTH DIAMETER W/FLAT (TiB2) (TiB2) secondary flute wall DC = +0,000/–0,008 DC APMX LF DCON W/FLAT design minimizes DCON = h 6 3,0 8,0 52,0 6,0 44505 49663 44506 49674 chip interference by directing chips away >6–10 DIAMETER 4,0 11,0 55,0 6,0 44509 49664 44510 49675 from secondary flute DC = +0,000/–0,009 5,0 13,0 57,0 6,0 44513 49665 44514 49676 • Circular land allows DCON = h 6 for increased control 6,0 13,0 57,0 6,0 44517 49666 44518 49677 at various speed and >10–18 DIAMETER 8,0 19,0 69,0 10,0 44521 49667 44522 49678 feed rates ultimately reducing chatter DC = +0,000/–0,011 10,0 22,0 72,0 10,0 44525 49668 44526 49679 • Recommended for DCON = h 6 12,0 26,0 83,0 12,0 44529 49669 44530 49680 materials ≤ 150 Bhn (≤ 7 HRc) >18–20 DIAMETER 14,0 26,0 83,0 14,0 44533 49670 44534 49681 DC = +0,000/–0,013 16,0 32,0 92,0 16,0 44537 49671 44538 49682 DCON = h 6 18,0 32,0 92,0 18,0 44541 49672 44542 49683 NON-FERROUS 20,0 38,0 104,0 20,0 44545 49673 44546 49684 PLASTICS/COMPOSITES Contact your KSPT Sales Representative for more information on Corner Radius options. For patent information visit www.ksptpatents.com 163 END MILLS www.kyocera-sgstool.com END MILLS
