Общий каталог PRECITOOL - страница 930

TORX® Allen wrench Design: - for female TORX® screws - with holding function - with two-component clip - blade zinc phosphatised, with hose coating - with colour coding and size marking 505523 long, colour-coded, with holding function TORX® profile 505523 Total length L × Hmm T8    90 × 16 T9  101 × 16 T10  112 × 19 T15  123 × 21 T20  137 × 24 T25  154 × 27 T27  172 × 31 T30  195 × 37 T40  224 × 42 505524 Set, long, colour-coded, with holding function Parts 505524 Contents 9  TX 8 | 9 | 10 | 15 | 20 | 25 | 27 | 30 | 40 TORX® Allen wrench titanium silver Design: - full-length blade of chromium-vanadium steel - titanium silver for better corrosion protection (no annoying oil on the key) - for female TORX® screws H 505527 long L TORX® profile 505527 Total length L × Hmm TORX® profile 505527 Total length L × Hmm T5  72 × 13 T20  148 × 29 T6  80 × 15 T25  163 × 33 T7  88 × 18 T27  176 × 36 T8  101 × 20 T30  191 × 38 T9  111 × 21 T40  210 × 43 T10  121 × 23 T45  232 × 49 T15  136 × 27 — — — 505527 Set, long Parts 505527 Contents 13  T5 | T6 | T7 | T8 | T9 | T10 | T15 | T20 | T25 | T30 | T40 | T45 50 TORX® ball point Allen key set kurzer Schenkel Design: - surface coated with titanium silver for corrosion protection 25° - spherical head geometry allows screwing under angles up to 25° - especially for hard-to-reach TORX® screws and operations in bottlenecks - TORX® ball point only from size T9 upwards 505529 short Parts 505529 Contents 13  T5 | T6 | T7 | T8 | T9 | T10 | T15 | T20 | T25 | T27 | T30 | T40 | T45 www.precitool.de 50/925 Wrenches
