TORX®/TORX PLUS® Product information Inner TORXh Sheet-metal screw Cylinder Counter- Raised Cylinder Oval head/ Counter- Oval Coun- Oval head/ sunk counter- Flat head sunk head tersunk Flat head sunk head TORXh DIN DIN DIN DIN DIN DIN DIN DIN DIN 912 963 964 7984 7985 7991 7981 7972 7973 965 966 6912 7982 7983 Size mm Torque TORXh Nm -M -B T5 1.42 0.43 * * * * * * * * * T6 1.70 0.75 * * * * * * * * * T7 1.99 1.40 * * * * * – – – – T8 2.31 2.20 2.5 2.5 2.5 – 2.5 2.5 2.9 2.9 2.9 T9 2.50 2.80 – – – – – – – – – T10 2.74 3.70 3.0 3.0 3.0 3.0 3.0 3.0 3.5 3.5 3.5 T15 3.27 6.40 – 3.5 3.5 – 3.5 3.5 3.9 3.9 3.9 T20 3.86 10.50 4.0 4.0 4.0 4.0 4.0 4.0 4.2 4.2 4.2 T25 4.43 15.90 5.0 5.0 5.0 5.0 5.0 5.0 5.8-5.5 5.8- 5.5 5.8-5.5 T27 4.99 22.50 ** ** ** ** ** ** ** ** ** T30 5.52 31.10 6.0 6.0 6.0 6.0 6.0 6.0 6.3 6.3 6.3 T40 6.65 54.10 8.0 8.0 8.0 8.0 8.0 8.0 – – – T45 7.82 86.00 ** ** ** ** ** ** ** ** ** T50 8.83 132.00 10.0 10.0 10.0 10.0 10.0 10.0 – – – T55 11.22 218.00 12.0 – – 12.0 – 12.0 – – – T60 13.25 379.00 14.0 – – 14.0 – – – – – Due to the reinforced core cross section of TORX PLUS®, compared to TORX® profiles, even higher torques can be transmitted. Revised profile flanks generate a balanced surface pressure between screw and tool instead of a high point loading. This protects both the screw and the tool and thus TORX PLUSh increases the service life. * Special screws for M 1.6 and 2.0 for carbide inserts ** Special screws TORX® screwdriver Design: - blade made of chromium-vanadium steel - handle made of impact-resistant plastic - through-hardened - especially suitable for tools with - surface manganese phosphatised HM indexable inserts 505450 with key handle 50 TORX® profile 505450 Blade lengthmm TORX® profile 505450 Blade lengthmm T5  35 T9  40 T6  35 T10  40 T7  35 T15  45 T8  40 T20  45 TORX PLUS® screwdriver Design: - blade made of chromium-vanadium steel - handle made of impact-resistant plastic - through-hardened - due to TORX PLUS® drive higher torques - surface manganese phosphatised than with TORX® profiles can be transmitted 505452 with key handle TORX PLUS® profile 505452 Blade lengthmm TORX PLUS® profile 505452 Blade lengthmm 5IP  35  9IP  40 6IP  35 10IP  40 7IP  35 15IP  45 8IP  40 20IP  45 www.precitool.de 50/923 Wrenches
