Dial Gauges/ Length Measuring High precision dial gauge Design: - with 1/1000 and 2/1000 mm scale division Factory - like 320220, though as oil- and waterproof version standard 320250 sealed dial Type 320250 Measuring spanmm Readingmm Pointer revolutionmm Box  Clamping shank  h6mmmm FM1000SW  1 0.001 0.2 61.5 8 High precision dial gauge Design: - the pin travel is magnified and transferred by a lever to the pointer Factory - measuring range division of 1 mm standard - due to the lever transmission, the reading range of inversion is very low at max. 1.5 µm - suited for very precise comparison measurements - deviation spans fe and fges are almost halved - measuring mechanism with the lever system offers a good impact protection Delivery: 32 With metal outer rings and lifting sleeves. 320320 with comparator precision movement Type 320320 Measuring spanmm Readingmm Pointer revolutionmm Box  Clamping shank  h6mmmm FM1101  1 0.001 0.1 58 8 Precision dial gauge Design:- with extreme robust metal housing and smooth-running mechanic- clamping shank made of stainless steel, hardened and fine groundFactoryDINstandard878 - pivotable scale for zero setting at any position - adjustable tolerance fingers - rod made of stainless steel, ground and micro-finished - exchangeable measuring insert, replaceable by special probes STO = impact-protected, without fine-adjustment of pointer 320400 320350 with large measuring range 320400 with large housing Type 320350 320400 Measuring spanmm Readingmm Pointer revolutionmm Box  Clamping shank  h6mmmm GM80 —   10 0.01 1  80  8 GM80SW —   10 0.01 1  80  8 GM100 —   10 0.01 1 100  8 M2/20  —  20 0.01 1  58  8 M2/30  —  30 0.01 1  58  8 M2/30STO  —  30 0.01 1  58  8 M2/50  —  50 0.01 1  58  8 M2/50STO  —  50 0.01 1  58  8 320350 M2/80  —  80 0.01 1  58  8 M2/100  — 100 0.01 1  80 10 32/688 www.precitool.de
