Micrometers Precision outside micrometer Design: Delivered - combined with a ratchet with feelable operation - for one-hand operation and use with holder in case - increased safety for one-hand operation - thimble and barrel scale matt chrome-plated, Ø 19 mm - planarity 0.6 µm - parallelism 2 µm 0-25 - measuring face carbide tipped, ultra fine lapped - frame varnished - measuring spindle pitch 0.5 mm with clamping feature,  6.35 mm - measuring force 5 - 10 N Delivery: Incl. hand guard, setting key, setting gauge (from 25 mm) and factory certificate 25-50 310230 MITUTOYO 102, reading 0.01 mm 310232 MITUTOYO 102, reading 0.001 mm Measuring rangemm 310230 310232 Error limitmm 0-25   0.004 25-50   0.004 Precision outside micrometer Design:- light-weight workshop version- resolution 0.01 mm DIN Delivered863/1in case - thimble and barrel scale matt chrome-plated- planarity 0.6 µm for versions up to 300 mm, beyond that 1 µm 31 - measuring faces carbide-tipped, ground and fine lapped - frame varnished - measuring spindle, pitch 0.5 mm with clamping feature - measuring force 5 - 10 N Delivery: Incl. setting gauge (from 25 mm), with factory certificate (up to 50 mm) and setting key 310235 MITUTOYO 103 Measuring rangemm 310235 Error limitmm Measuring rangemm 310235 Error limitmm 0-25  0.004 150-175  0.008 25-50  0.004 175-200  0.008 50-75  0.004 200-225  0.008 75-100  0.006 225-250  0.010 100-125  0.006 250-275  0.010 125-150  0.006 275-300  0.010 Precision outside micrometer set Design:- set consisting of 310230 and 310235 DIN Delivered - resolution 0.01 mm 863/1 in case - thimble and barrel scale matt chrome-plated - measuring faces carbide-tipped, ground and fine lapped - frame varnished - measuring spindle, pitch 0.5 mm with clamping feature - measuring force 5 - 10 N Delivery: Incl. setting key, setting gauge (from 25 mm) and factory certificate (up to 50 mm). 310237 MITUTOYO 103, set Measuring rangemm 310237 Contents Outside micrometer (310230) 0-25 mm, 0-150  Outside micrometer (310235) 25-50 | 50-75 | 75-100 | 100-125 | 250-125 | 275-150 mm 5 setting standards for external micrometers Outside micrometer (310235) 150-300  150-175 | 175-200 | 200-225 | 225-250 | 250-275 | 275-300 mm 6 setting standards for outside micrometers 0-300  External micrometer (310230) 0-25 mm,Outside micrometer (310235) 25-50 to 275-300 mm www.precitool.de 31/655
