Clamping Devices Clamping devices and accessories Design: Made of tempered steel galvanised, grade 6 Use: - slide the nut sideways on the screw thread to the clamping point and lock it - lock the upper with the lower part by ¼ to ½ revolution Quick-release nut also available with collar in size M16-M24 297820 Quick-release nut without collar Thread 297820 m AFmmmm Thread 297820 m AFmmmm M6   9.0 16 M12  15.0 27 M8  10.5 19 M16  16.0 34 M10  12.5 22 M20  22.0 41 Design: DIN Tempered (350 + 80 HV 30), punched and gauged 6340 Use:With clamp, high nuts etc. 29 297850 Washer DIN 6340 Thread 297850 d1mm d2 smmmm Thread 297850 d1mm d2 smmmm M6   6.4 17 3 M18  19.0 45  6 M8   8.4 23 4 M20  21.0 50  6 M10  10.5 28 4 M22  23.0 50  8 M12  13.0 35 5 M24  25.0 60  8 M14  15.0 40 5 M30  31.0 68 10 M16  17.0 45 6 — — — — — Design:Case-hardened and phosphatised DIN6319 C 297860 Spherical washer DIN 6319C Thread 297860 d1mm d2mm h2mm Rmm Thread 297860 d1mm d2mm h2mm Rmm M6   6.4 12 2.3  9 M16  17.0 30  5.3 22 M8   8.4 17 3.2 12 M20  21.0 36  6.3 27 M10  10.5 21 4.0 15 M24  25.0 44  8.2 32 M12  13.0 24 4.6 17 M30  31.0 56 11.2 41 M14  15.0 28 5.0 22 — — — — — — Design and use:- case-hardened and phosphatised- designed for screw strength in compliance with 8.8DIN6319 D - limited for use on flat closed ring surfaces - not permitted for slotted holes - for that purpose we recommend spherical washers DIN 6319G 297870 Spherical washer DIN 6319D Thread 297870 d2mm max. d4kNmm h3mm Thread 297870 d2mm max. d4kNmm h3mm M6   7.1  9 12 2.8 M16  19.0  73 30  6.2 M8   9.6 17 17 3.5 M20  23.2 117 36  7.5 M10  12.0 26 21 4.2 M24  28.0 168 44  9.5 M12  14.2 38 24 5.0 M30  35.0 269 56 12.0 M14  16.5 53 28 5.6 — — — — — — Design and use: - DIN, punched, pressed and tempered- suited to match slotted clamps DIN6319 G 297880 Spherical washer DIN 6319D Thread 297880 d2mm d5 h3mmmm Thread 297880 d2mm d5 h3mmmm M6   7.1 17 4 M16  19.0 44  7 M8   9.6 24 5 M20  23.2 50  8 M10  12.0 30 5 M24  28.0 60 10 M12  14.2 36 6 M30  35.0 68 10 M14  16.5 40 6 — — — — — www.precitool.de 29/607
