Vices / Clamping Devises Permanent magnet Design: Round cross-section. Pole marked by notch. Delivery always in pairs. Application temperature up to 450 °C. Use: For stringing together single magnets up to any desired length. 279780 Bar magnet, round cross section d1 × l1mm 279780 6×20  8×25  10×30  Design: Rectangular cross-section. Pole marked by notch. Delivery always in pairs. Application temperature up to 450 °C. Use: For stringing together single magnets up to any desired length. 27 279790 Bar magnet, rectangular cross section b × h × l1mm 279790 10×5×20  12×5×60  12,5×5×40  15×5×60  15×10×75  15×10×100  Design: Arch form magnet with high holding power, with through hole for mounting. Application temperature up to 450 °C. Use: For holding, lifting and sorting. 279850 Strong magnet with bore Size 279850 hmm Pole distance/Cross-sectionmm Adhesive powerN Weightkg 1  20   5/  8 × 20.0  45 0.065 2  25 20/10 × 25.0  90 0.150 3  30 22/11 × 29.0 120 0.220 4  35 35/11 × 35.5 230 0.380 Design: With threaded bush, application temperature up to 200 °C. Flat pot magnets made of ceramic permanent magnet material OXIT 380 are provided with a shielding pot made of soft iron. Surface galvanised. adhesive surface 279900 Flat gripper with threaded bush, made of OXIT d1mm 279900 Hmm hmm d2mm G Thread length approx. Adhesive power Dead weight approx.mmNg 10  11.5 4.5 6 M3 5 4 4 13  11.5 4.5 6 M3 5 10 5 16  11.5 4.5 6 M3 5 18 6 20  13.0 6.0 6 M3 5 30 11 25  15.0 7.0 8 M4 6 40 22 32  15.0 7.0 8 M4 6 80 32 40  18.0 8.0 10 M5 8 125 60 50  22.0 10.0 12 M6 10 220 110 63  30.0 14.0 15 M8 14 350 240 www.precitool.de 27/587
