Tool Holders PSCHST A Spindle tool Design: - ST+ extension without traction bolt and threaded ring- further accessories available on request JIS ISO Form6339 B7388-2AD 239012 Basic tool holder ISO 7388-2 (JIS 6339 B) form AD Type 239012 BT ST Dmm d1 Amm Lmm Thread A L 3050  30 ST5 50 28 38 16 M12 4010  40 ST1 20 11 42 15 M16 4020  40 ST2 25 14 42 15 M16 4030  40 ST3 32 18 44 17 M16 M d1 D 4040  40 ST4 39 22 48 21 M16 4050  40 ST5 50 28 55 28 M16 4061  40 ST6+ 64 36 46 19 M16501050ST120116325M24502050ST225146325M24 23 5030  50 ST3 32 18 65 27 M24 5040  50 ST4 39 22 69 31 M24 5050  50 ST5 50 28 72 34 M24 5061  50 ST6+ 64 36 72 34 M24 5071  50 ST7+ 90 46 86 48 M24 Design:- ST+/HST with thread ring and without traction bolt- further accessories available on request DIN69893 ISO12164A/CForm A 239014 Basic tool holder ISO 12164-1 (DIN 69893) form A Type 239014 HST A ST Dmm d 1 Amm Lmm 6310  63 ST1 20 11 42 16632063ST225144216 D d1 6330  63 ST3 32 18 44 18 6340  63 ST4 39 22 48 22 6350  63 ST5 50 28 59 33 L 6360  63 ST6 64 36 70 44 A 6361  63 ST6+ 64 36 100 74 1010  100 ST1 20 11 55 26 1020  100 ST2 25 14 55 26 1030  100 ST3 32 18 57 28 1040  100 ST4 39 22 61 32 1050  100 ST5 50 28 72 43 1060  100 ST6 64 36 78 49 1061  100 ST6+ 64 36 108 79 1071  100 ST7+ 90 46 127 98 Design:- ST+ extension without traction bolt and threaded ring- further accessories available on request ISO26623-1 D d1 239016 Tool holder ISO 26623-1 L Type 239016 PSC ST Dmm d 1 Amm Lmm A 6310  63 ST1 20 11 65 43 6320  63 ST2 25 14 65 43 6330  63 ST3 32 18 65 43 6340  63 ST4 39 22 58 36 6350  63 ST5 50 28 48 26 6360  63 ST6 64 36 59 37 6361  63 ST6+ 64 36 94 72 www.precitool.de 23/391
