B Tailstock Centres / Arbors Revolving centring taper Design: - robust construction - high concentricity - centring taper and receiving shank drop-forged, hardened and ground - permanent lubrication with special grease, maintenance-free Use: D - for heavy-duty cutting work - for machining of pipes and hollow bodies B E A 222300 blunt, 60 degree 222350 blunt, 75 degree Morse taper/B 222300 Amm Bmm D Emmmmmax. workpieceweightmax. radialdeviationmm2/5065.0 5020522000.008Morse taper/B222350A B D E max. workpiecemmmmmmmmweightmax. radialdeviationmm2/80 80.0 80 20 67  3000.00822 2/80  77.0  80 30 64 300 0.008 3/80   80.0  80  20  67   400 0.008 3/80  77.0  80 30 64 400 0.008 4/80   81.5  80  20  67   400 0.008 4/80  78.5 80 30 64 400 0.008 3/120   85.5 120  30  72   600 0.008   3/120  96.5 120 30 83 600 0.008 4/120   87.0 120  30  72   800 0.008   4/120  98.0 120 30 83 800 0.008 5/120   88.0 120  30  72   800 0.008   5/120  99.0 120 30 83 800 0.008 4/170  107.0 170  50  90 1,200 0.010 5/170  106.0 170  50  90 1,600 0.010 6/170  107.5 170  50  90 1,600 0.010 5/250  146.5 250  75 130 2,000 0.010 6/250 + 148.0 250  75 130 2,000 0.010 6/350 + 184.0 350 120 168 4,000 0.015 Design: - robust construction - high concentricity - centring taper and receiving shank drop-forged, hardened and ground - permanent lubrication with special grease, maintenance-free Use: - for heavy-duty cutting work - centring taper for hollow body - centre point for machining of standard workpieces 222920 pointed, 60 degree Morse taper/B 222920 Amm B H max. workpiece weight max. radial deviationmmmmkgmm 2/42   61.0 42 7.0   200 0.010 3/56   79.0 56 7.0   400 0.008 4/64  100.0 64 8.5   800 0.008 5/78  115.5 78 8.5 1,600 0.008 Chip hook Chip collector Design: Design: - with hand shield Ø 140 Integrated mm made of GRP permanent magnet - material Ø of hook at shield 6 mm Use: - ergonomic handle in For sharp-edged 2-component injection magnetic metal chips in moulding technique hard-to-reach places 225370 with hand shield 225380 magnetic Hook lengthmm300 225370 Total lengthmm 225380 Diametermm Weightkg 500  300  25 0.6 www.precitool.de 22/327
