HSS / HSSE End Mill End mill HSS-Co Cat. no. PN/mm2 MN/mm2 KHB SN/mm2 NN/mm2161701 HSS-Co coated DIN Type Teeth327N2 25°Twist Centre cut <1000 < 850 < 240 Titanium <1200 Alu < 600 Brass < 600 161706 vc = m/min. 1835 B UNI 161701 12-30 10-20 10-20 5-12 50-150 30-60 shank short P9 161706 20-60 30-40 35-50 20-60 100-210 75-100 16 161701 PRECITOOL, HSS-Co, short, sharp-edged 161706 PRECITOOL, HSS-Co, short, sharp-edged, TiAlN d1mm 161701 161706 l1mm l2mm d2mm fzmm/tooth 2,00   48 4 6 0.001 - 0.005 2,50   49 5 6 0.001 - 0.005 3,00   49 5 6 0.003 - 0.010 3,50   50 6 6 0.003 - 0.010 4,00   51 7 6 0.006 - 0.015 4,50   51 7 6 0.006 - 0.015 5,00   52 8 6 0.007 - 0.020 5,50   52 8 6 0.007 - 0.0206,0052860.014 - 0.03090° d1 (e8) 6,50   60 10 10 0.009 - 0.025 7,00   60 10 10 0.009 - 0.025 7,50   60 10 10 0.009 - 0.0258,006111100.014 - 0.030 161701 8,50   61 11 10 0.014 - 0.030 9,00   61 11 10 0.014 - 0.030 9,50   61 11 10 0.014 - 0.030 10,00   63 13 10 0.018 - 0.035 11,00   70 13 12 0.018 - 0.035 90° d (e8)1 12,00   73 16 12 0.022 - 0.045 13,00   73 16 12 0.022 - 0.045 14,00   73 16 12 0.022 - 0.045 15,00   73 16 12 0.022 - 0.045 161706 16,00   79 19 16 0.027 - 0.055 17,00   79 19 16 0.027 - 0.055 18,00   79 19 16 0.027 - 0.055 19,00   79 19 16 0.027 - 0.055 20,00   88 22 20 0.033 - 0.065 22,00   88 22 20 0.033 - 0.065 24,00   102 26 25 0.033 - 0.065 25,00   102 26 25 0.033 - 0.065 End mill HSS-PM Cat. no. PN/mm2 KHB SN/mm2 NN/mm2161922<1000< 240Titanium <1400Alu < 600Copper HSS- DIN Type TeethPM327Ncoated225°Twist Centre cut vc = m/min. 161922 20-80 35-65 30-45 90-420 100-110 1835 B UNI shank short P9 161922 PRECITOOL, HSS-PM, short, sharp-edged, AlTiN d1mm 161922 l 1mm l 2mm d 2mm fzmm/tooth 4,00  51 7 6 0.012 - 0.015 5,00  52 8 6 0.012 - 0.015 6,00  52 8 6 0.018 - 0.0258,006111100.021 - 0.03790° d1 (e8) d2 (h6) 10,00  63 13 10 0.035 - 0.046 12,00  73 16 12 0.041 - 0.055 16,00  79 19 16 0.070 - 0.076 18,00  79 19 16 0.070 - 0.076 20,00  88 22 20 0.070 - 0.090 16/222 www.precitool.de
