Tap Drills Machine tap Inox Cat. no. PN/mm2 MN/mm2 SN/mm2 N Design:N/mm2- for blind hole thread135430< 1100< 800Titanium < 900Nickel < 900- chamfer form C, 2-3 threadMHSS-E DIN Chamfer form C Metric60° DINMetricV3371L13thread40°Twist2-3 threads - high-speed steel with vanadium content vc = m/min. - vaporised1354306-86-82-42-4 6H 2.5 × D M Use: Blind hole Especially for stainless steels. 13 135430 PRECITOOL, HSSE-V3, RSP40, vaporised d1mm 135430 Pmm l 1 l2 l4mmmmmm d2mm a l3 Core mmmmmm M2  0.40 45 8 —  2.8 2.1 5 1.60 M2,5  0.45 50 9 —  2.8 2.1 5 2.05 M3  0.50 56 5 18  3.5 2.7 6 2.50 M3,5  0.60 56 6 20  4.0 3.0 6 2.90 M4  0.70 63 7 21  4.5 3.4 6 3.30 M5  0.80 70 8 25  6.0 4.9 8 4.20 M6  1.00 80 10 30  6.0 4.9 8 5.00 M8  1.25 90 13 35  8.0 6.2 9 6.80 M10  1.50 100 15 39 10.0 8.0 11 8.50 Cat. no. PN/mm2 MN/mm2 SN/mm2 NN/mm2 M HSS-E DIN Chamfer form C Metric60° DINMetricV3376L13 135435 < 1100 < 800 Titanium < 900 Nickel < 900 thread 40°Twist 2-3 threads vc = m/min. 135435 6-8 6-8 2-4 2-4 6H 2.5 × D M Blind hole 135435 PRECITOOL, HSSE-V3, RSP40, vaporised d1mm 135435 Pmm l1 l2mmmm d2mm amm l3 Core mmmm M3  0.50 56 5  2.2 — —  2.50 M4  0.70 63 7  2.8  2.1 5  3.30 M5  0.80 70 8  3.5  2.7 6  4.20 M6  1.00 80 10  4.5  3.4 6  5.00 M8  1.25 90 13  6.0  4.9 8  6.80 M10  1.50 100 15  7.0  5.5 8  8.50 M12  1.75 110 18  9.0  7.0 10 10.20 M14  2.00 110 20 11.0  9.0 12 12.00 M16  2.00 110 20 12.0  9.0 12 14.00 M18  2.50 125 25 14.0 11.0 14 15.50 M20  2.50 140 25 16.0 12.0 15 17.50 M22  2.50 140 25 18.0 14.5 17 19.50 M24  3.00 160 30 18.0 14.5 17 21.00 M27  3.00 160 30 20.0 16.0 19 24.00 M30  3.50 180 35 22.0 18.0 21 26.50 M36  4.00 200 40 28.0 22.0 25 32.00 Machine tap Inox Cat. no. MN/mm2 SN/mm2 NN/mm2135485< 1300Brass, bronze, alu < 600Thermoplastics,CFRP, GFRPM HSS- DIN DIN Chamfer form CMetricCo PMthreadcoated371376from M1250°TwistL2-3 threadsMetric vc = m/min. 60° DIN13 6H 3×D M 135485 8-10 2-4 32-60 15-26 Blind hole Design/use: Dimensions: - for blind hole threads ≤ M6 = solid point - chamfer form C, 2-3 thread > M6 = internal centring - like 135085 135485 HighQ, HSS-Co PM, RSP50, TiCN d1mm 135485 Pmm l1 l2 l4mmmmmmd2mm amm l3 Core mmmm M3  0.50 56 5 18  3.5  2.7 6  2.50 Inox M4  0.70 63 7 21  4.5  3.4 6  3.30 M5  0.80 70 8 25  6.0  4.9 8  4.20 M6  1.00 80 10 30  6.0  4.9 8  5.00 M8  1.25 90 13 35  8.0  6.2 9  6.80 M10  1.50 100 15 39 10.0  8.0 11  8.50 M12  1.75 110 18 —  9.0  7.0 10 10.20 M14  2.00 110 20 — 11.0  9.0 12 12.00 M16  2.00 110 20 — 12.0  9.0 12 14.00 M18  2.50 125 25 — 14.0 11.0 14 15.50 M20  2.50 140 25 — 16.0 12.0 15 17.50 M22  2.50 140 25 — 18.0 14.5 17 19.50 M24  3.00 160 30 — 18.0 14.5 17 21.00 M27  3.00 160 30 — 20.0 16.0 19 24.00 M30  3.50 180 35 — 22.0 18.0 21 26.50 13/188 www.precitool.de
