P M S Design: M Chamfer form B Metric
Cat. no. - for through-hole threads HSS-E DIN 60° DIN
N/mm2 N/mm2 N/mm2 6H
- chamfer form B, 3.5-5 thread Metric V3 371 13
| 135020 | < 1100 | < 800 Titanium < 900 | thread | L | |
| 3,5-5 threads | |||||
| - high-speed steel with vanadium content |
vc = m/min. - vaporised M
| 135020 | 8-12 | 6-8 | 2-4 | |||
| Use: | Through hole | |||||
| 13 | Especially for stainless steels. | |||||
| 135020 PRECITOOL, HSSE-V3, vaporised |
| d | P | l | l | l | d | a | l | Core x | |
| 1 | 135020 | 1 | 2 | 4 | 2 | 3 | |||
| mm | mm | mm | mm | mm | mm | mm | mm | mm | |
| M2 | | 0�40 | 45 | 8 | — | 2�8 | 2�1 | 5 | 1�60 |
| M2,5 | | 0�45 | 50 | 9 | — | 2�8 | 2�1 | 5 | 2�05 |
| M3 | | 0�50 | 56 | 11 | 18 | 3�5 | 2�7 | 6 | 2�50 |
| M3,5 | | 0�60 | 56 | 12 | 20 | 4�0 | 3�0 | 6 | 2�90 |
| M4 | | 0�70 | 63 | 13 | 21 | 4�5 | 3�4 | 6 | 3�30 |
| M5 | | 0�80 | 70 | 16 | 25 | 6�0 | 4�9 | 8 | 4�20 |
| M6 | | 1�00 | 80 | 19 | 30 | 6�0 | 4�9 | 8 | 5�00 |
| M8 | | 1�25 | 90 | 22 | 35 | 8�0 | 6�2 | 9 | 6�80 |
| M10 | | 1�50 | 100 | 24 | 39 | 10�0 | 8�0 | 11 | 8�50 |
P M S M HSS-E DIN Chamfer form B Metric DIN
Cat. no. 60° 6H
| N/mm2 | N/mm2 | N/mm2 | V3 | 13 376 | ||
| Metric | ||||||
| 135030 | < 1100 | < 800 Titanium < 900 | thread | L | ||
| 3,5-5 threads | ||||||
| vc = m/min. | M | |||||
| 135030 | 8-12 | 6-8 | 2-4 | |||
| Through hole | ||||||
| 135030 PRECITOOL, HSSE-V3, vaporised |
| d | P | l | l | d | a | l | Core x | |
| 1 | 135030 | 1 | 2 | 2 | 3 | |||
| mm | mm | mm | mm | mm | mm | mm | mm | |
| M3 | | 0�50 | 56 | 11 | 2�2 | — | — | 2�50 |
| M4 | | 0�70 | 63 | 13 | 2�8 | 2�1 | 5 | 3�30 |
| M5 | | 0�80 | 70 | 16 | 3�5 | 2�7 | 6 | 4�20 |
| M6 | | 1�00 | 80 | 19 | 4�5 | 3�4 | 6 | 5�00 |
| M8 | | 1�25 | 90 | 22 | 6�0 | 4�9 | 8 | 6�80 |
| M10 | | 1�50 | 100 | 24 | 7�0 | 5�5 | 8 | 8�50 |
| M12 | | 1�75 | 110 | 28 | 9�0 | 7�0 | 10 | 10�20 |
| M14 | | 2�00 | 110 | 30 | 11�0 | 9�0 | 12 | 12�00 |
| M16 | | 2�00 | 110 | 32 | 12�0 | 9�0 | 12 | 14�00 |
| M18 | | 2�50 | 125 | 34 | 14�0 | 11�0 | 14 | 15�50 |
| M20 | | 2�50 | 140 | 34 | 16�0 | 12�0 | 15 | 17�50 |
| M22 | | 2�50 | 140 | 34 | 18�0 | 14�5 | 17 | 19�50 |
| M24 | | 3�00 | 160 | 38 | 18�0 | 14�5 | 17 | 21�00 |
| M27 | | 3�00 | 160 | 38 | 20�0 | 16�0 | 19 | 24�00 |
| M30 | | 3�50 | 180 | 45 | 22�0 | 18�0 | 21 | 26�50 |
| M36 | | 4�00 | 200 | 56 | 28�0 | 22�0 | 25 | 32�00 |
| Machine tap Inox |
M S N Plastics M HSS- DIN Chamfer form B Metric
Cat. no. DIN 60°
| N/mm2 | N/mm2 | N/mm2 | N/mm2 | Co PM | 371 | 376 | |
| Metric |
| thread | from M12 | L | |
| coated | 3,5-5 threads |
| 135085 | < 1300 | Brass, bronze, alu < 600 Thermoplastics, | ||||
| CFRP, GFRP | ||||||
| DIN | M | |||||
| vc = m/min. | 6H | |||||
| 13 |
135085 8-10 2-4 32-60 15-26
Through hole Design/Use: - for through-hole threads - chamfer form B, 3.5-5 thread
- machine tap made of powder metallurgical HSS (PS55) with very good cutting performance, strength and process reliability. The TiCN coating minimizes formation of built-up edges, and significantly contributes to a brilliant chip formation. Special Inox geometry.
Dimensions: ≤ M6 = solid point > M8 = internal centring
135085 HighQ, HSS-Co PM, TiCN
| d | P | l | l | l | d | a | l | Inox Core x | |
| 1 | 135085 | 1 | 2 | 4 | 2 | 3 | |||
| mm | mm | mm | mm | mm | mm | mm | mm | mm | |
| M3 | | 0�50 | 56 | 11 | 18 | 3�5 | 2�7 | 6 | 2�50 |
| M4 | | 0�70 | 63 | 13 | 21 | 4�5 | 3�4 | 6 | 3�30 |
| M5 | | 0�80 | 70 | 16 | 25 | 6�0 | 4�9 | 8 | 4�20 |
| M6 | | 1�00 | 80 | 19 | 30 | 6�0 | 4�9 | 8 | 5�00 |
| M8 | | 1�25 | 90 | 22 | 35 | 8�0 | 6�2 | 9 | 6�80 |
