Hand deburrer

- for neat deburring by hand and spotfacing of holes, mainly during assembly work HSS - fit for all materials - with 3 cutting edges, radial relief ground

110200 PRECITOOL, HSS, 90°, with plastic handle

dd11 l
111020031
mmmmmm
12,42�8133
16,53�2135
20,53�5138
25,03�8142
Countersink

P M K S N Form 90°

Cat. no. HSS UNI

N/mm2N/mm2HBN/mm2N/mm2C
Straight
shank
110210< 850< 750< 250Titanium Copper, brass,Plastics
Alu < 600
vc = m/min.
11021018-284-108-204-1010-8010-80

Design: - 3 cutting edges, radial relief ground - with extended shank (100 mm)

110210 PRECITOOL, HSS, 90°, with extended shank

d1 mm110210d3 mml1 mmd2 mmf mm/U
8,32�010560�050 - 0�140
10,42�510760�050 - 0�140
12,42�810880�060 - 0�180
16,53�2111100�080 - 0�200
20,53�5114100�090 - 0�240

Countersink

PMKSNDINForm90°UNI
Cat. no.HSS
N/mm2N/mm2HBN/mm2N/mm2335D
MK

110260 < 850 coated shank

< 750 < 250 Titanium Copper, brass, Plastics

110265<1000Alu < 600
vc = m/min.
110260

18-28 4-10 8-20 4-10 10-80 10-80

110265 Design: - 3 cutting edges, radial relief ground - 110265 TiN coated to increase cutting performance and tool life

110260

110260 PRECITOOL, HSS, 90°, with MT shank

110265

110265 PRECITOOL, HSS, 90°, with MT shank, TiN

d1 mm110260110265d3 mml1 mmMTf mm/Ufor countersunk screws DIN 7991for countersunk screws DIN 963/964/965/966
16,5—3�28510�080 - 0�200—M 8
20,5—3�510020�090 - 0�240—M 10
25,03�810620�120 - 0�300—M 12
28,0—4�010620�120 - 0�300—M 14
30,0—4�210620�120 - 0�300M 16—
31,04�210620�120 - 0�300—M 16
34,0—4�511820�120 - 0�300M 18M 18
37,04�811820�120 - 0�300M 20M 20
40,010�014030�140 - 0�400——
50,014�015030�140 - 0�400——
63,016�018040�140 - 0�400——
80,0—22�019040�140 - 0�400——
