Key puller Design: With the help of this tool stuck wedges from keyways of shafts can be extracted easily and without damage Feather key Use: First adjust the clamping jaws to the width of the stuck wedge by turning the handle (1) and fully extend them to the stop by turning the knob (2). D Then place the tongs and tighten the hand wheel to secure the jaw clamps on the wedge. Tightening the hand wheel activates the eccentric mechanism and pulls the wedge upwards out of the groove. To remove the extracted wedge from the forceps, open B the clamping jaws by turning the hand wheel back to the initial position. A (1) C (2) 590895 Key puller Type 590895 A/B/C/Dmm Clamping rangemm 139 - 1  0 - 35, 110, 122 - 144, 236  3 - 35  Fork separator Stud extractor Design: Design: - made of hardened special steel - a useful version for confined spaces - handle bar knurled - actuation through ring spanner or socket wrench - with massive forked wedge head Use: For loosening track rod ends, shock absorbers, pit- man arms etc., especially under narrow conditions. After the wedge-shaped fork end has been positio- ned, the parts are separated by hammer strokes 590910 separate 590900 wedge-shaped fork head Xmm 590910 Hexagonmm Squaremm 6  21 1/2" Type 590900 Fork openingmm 7  21 1/2"8211/2" 135/1  18 10  21 1/2" 135/2  23 12  21 1/2" 135/3  29 16  27 round 59 Stud extractor set Stud extractor Design: Design and use: 4-piece set in plastic case - large clamping range - due to low arrangement of the knurl wheel even short ends of studs can be seized 590915 4-piece 590920 Clamping range 5 - 19 mm Type 590915 Contents Type 590920 Clamping rangemm 53  one puller each 6 mm, 8 mm, 10 mm and 12 mm 52  5 - 19  www.precitool.de 59/1153 Pullers / Sheet Metal Treatment
