WXL-LN-EBD

Фрезерование | Твердый сплав

Фреза из твердого сплава с покрытием WXL

  • Для сталей закаленных до 52 HRC и нержавеющих сталей
  • Двухзубая, длинная шейка, сферическая
  • 284 типоразмеров

Область применения

P ◉~45 HRCP ◉~55 HRCM ◉~35 HRCK ◉~350 HBN ○S ○H ○~60 HRC

Характеристики

Материал: Твердый сплав (CARBIDE) | Покрытие: WXL | Главный угол в плане: 30˚ | Крепление: SHRINK FIT | Допуск на радиус: ± 0,005

EDPZDRl1LldD1ΦkLe (α) 0,5ºLe (α) 1ºLe (α) 1,5ºLe (α) 2ºLe (α) 2,5ºLe (α) 3º
311010320,10,050,3450,0840,08514,460,340,350,360,370,380,4
311010520,10,050,5450,0840,08514,10,540,560,580,60,620,64
311020320,20,10,3450,1640,1814,590,30,310,320,330,340,35
311020520,20,10,5450,1640,1814,440,530,550,570,590,610,63
312020520,20,10,5500,1660,1814,160,530,550,570,590,610,63
311020720,20,10,75450,1640,1813,720,790,820,850,880,910,94
311021020,20,11450,1640,1813,311,051,091,131,171,211,26
312021020,20,11500,1660,1813,851,051,091,131,171,211,26
311021220,20,11,25450,1640,1812,921,311,361,411,461,511,57
311021520,20,11,5450,1640,1812,561,571,631,681,741,811,88
312021520,20,11,5500,1660,1813,31,571,631,681,741,811,88
311021720,20,11,75450,1640,1812,211,831,91,962,032,112,19
311022020,20,12450,1640,1811,882,092,162,242,322,42,5
312022020,20,12500,1660,1812,82,092,162,242,322,42,5
311022520,20,12,5450,1640,1811,282,612,72,792,8933,12
311023020,20,13450,1640,1810,733,133,233,353,473,63,74
311030520,30,150,5450,2440,2814,220,520,540,560,580,60,62
311030620,30,150,6450,2440,2814,030,630,650,680,70,720,75
311030720,30,150,75450,2440,2813,770,790,820,850,870,90,93
311031020,30,151450,2440,2813,341,051,091,121,161,21,24
312031020,30,151500,2460,2813,881,051,091,121,161,21,24
311031220,30,151,25450,2440,2812,941,311,361,41,451,51,55
311031520,30,151,5450,2440,2812,571,571,631,681,741,81,87
312031520,30,151,5500,2460,2813,331,571,631,681,741,81,87
311031720,30,151,75450,2440,2812,211,831,891,962,022,12,18
311032020,30,152450,2440,2811,872,092,162,232,312,42,49
312032020,30,152500,2460,2812,812,092,162,232,312,42,49
311032220,30,152,25450,2440,2811,562,352,432,512,62,692,8
311032520,30,152,5450,2440,2811,252,612,692,792,892,993,11
312032520,30,152,5500,2460,2812,342,612,692,792,892,993,11
311032720,30,152,75450,2440,2810,972,872,963,063,173,293,42
311033020,30,153450,2440,2810,693,133,233,343,463,593,73
312033020,30,153500,2460,2811,893,133,233,343,463,593,73
311033520,30,153,5450,2440,2810,193,643,763,94,044,194,35
311034020,30,154450,2440,289,724,164,34,454,614,784,97
311034520,30,154,5450,2440,289,34,684,8355,195,385,59
311035020,30,155450,2440,288,915,195,375,565,765,986,22
311040520,40,20,5450,340,3714,30,520,530,550,560,580,6
311040720,40,20,75450,340,3713,830,780,80,830,850,880,91
311041020,40,21450,340,3713,391,041,071,111,141,181,22
312041020,40,21500,360,3713,931,041,071,111,141,181,22
311041520,40,21,5450,340,3712,591,561,611,661,721,771,84
312041520,40,21,5500,360,3713,361,561,611,661,721,771,84
311042020,40,22450,340,3711,882,082,142,212,292,372,46
312042020,40,22500,360,3712,832,082,142,212,292,372,46
