d k A-CSF Advanced Performance Carbide Coolant-Through Taps for Cast Iron and Aluminum Alloy List 16600 NEW CARBIDE BR 15˚ A-CSF, Coolant - Through, DIN Overall Length, Modified Bottom (2.5P -), Bottom (1.5P) Lc Ln L lk EDP Number Tap Size Thread No. ofLimitFlutesBottom(1.5P) ModBottom DINOverallLengthThreadLengthNeckLengthShank Dia. SquareWidthSquareLength(2.5P) Bright Bright L Lc Ln d k lk M5 x 0.8 D4 1660000000 1660000100 70 10 25.0 4.92 3.86 6.3 M6 x 1.0M8 x 1.25M10 x 1.5M10 x 1.25D5D6D51660000200 1660000300 8031660000400166000050016600006001660000700166000080016600009009010012151831.06.474.857.935.08.076.049.539.09.677.2611.1 M12 x 1.75 D6 1660001000 1660001100 110 21 - 9.32 6.98 Packed: 1 pc. EDP’s listed above are stocked standard, other coatings available upon request. ATP Specify treatment at time of order. Note: Reduce SFM 50% - 70% while using external coolant. Work Material P M K N S H Carbon Steels AlloyList No.Low10101018Med.10351045HighSteelsDie10654140Steels4340Stainless SteelsCast30040017-4 PHIronAluminumNickelAlloyTitaniumHardened Steels60617075CastingInconel6Al4V(30 HRC)~35HRC35-4545-5050-70HRCHRCHRC 16600 SFM 15-50 30-330 30-330 good best WWW.OSGTOOL.COM Spiral Fluted Taps 413
