VPH-GDS, Ideal for Difficult to Machine Materials
SPEED
FEED XPM STUB
V 30˚ P318-319
| EDP | Diameter | Flute Length | Overall Length | Shank Diameter | Point Angle | ||||
| Number | |||||||||
| Fractional Size | Wire Gage | Letter Size | mm | Inch | FL | L | d | α | |
| 8608445 | - | - | - | 4.45 | 0.1752 | ||||
| 9599045 | - | 16 | - | 4.50 | 0.1772 | ||||
| 8608457 | - | 15 | - | 4.57 | 0.1799 | ||||
| 9599046 | - | - | - | 4.60 | 0.1811 | 24.0 | 68 | ||
| 8608462 | - | 14 | - | 4.62 | 0.1819 | ||||
| 8608466 | - | - | - | 4.66 | 0.1835 | ||||
| 9599047 | - | 13 | - | 4.70 | 0.1850 | ||||
| 8608476 | 3/16 | - | - | 4.76 | 0.1874 | ||||
| 8608479 | - | - | - | 4.79 | 0.1886 | ||||
| 9599048 | - | 12 | - | 4.80 | 0.1890 | ||||
| 8608485 | - | 11 | - | 4.85 | 0.1909 | ||||
| 9599049 | - | - | - | 4.90 | 0.1929 | ||||
| 8608491 | - | - | - | 4.91 | 0.1933 | ||||
| 8608498 | - | 9 | - | 4.98 | 0.1961 | ||||
| 9599050 | - | - | - | 5.00 | 0.1969 | ||||
| 8608505 | - | 8 | - | 5.05 | 0.1988 | ||||
| 9599051 | - | - | - | 5.10 | 0.2008 | 26.0 | |||
| 8608511 | - | 7 | - | 5.11 | 0.2012 | 70 | |||
| 8608515 | - | - | - | 5.15 | 0.2028 | ||||
| 8608516 | 13/64 | - | - | 5.16 | 0.2031 | 6 | |||
| 8608518 | - | 6 | - | 5.18 | 0.2039 | ||||
| 9599052 | - | - | - | 5.20 | 0.2047 | ||||
| 8608522 | - | 5 | - | 5.22 | 0.2055 | 130° | |||
| 8608526 | - | - | - | 5.26 | 0.2071 | ||||
| 9599053 | - | - | - | 5.30 | 0.2087 | ||||
| 8608531 | - | 4 | - | 5.31 | 0.2091 | ||||
| 9599054 | - | - | - | 5.40 | 0.2126 | ||||
| 8608541 | - | - | - | 5.41 | 0.2130 | ||||
| 8608546 | - | - | - | 5.46 | 0.2150 | ||||
| 9599055 | - | - | - | 5.50 | 0.2165 | ||||
| 8608556 | 7/32 | - | - | 5.56 | 0.2189 | 72 | |||
| 9599056 | - | - | - | 5.60 | 0.2205 | ||||
| 8608561 | - | 2 | - | 5.61 | 0.2209 | 28.00 | |||
| 9599057 | - | - | - | 5.70 | 0.2244 | ||||
| 8608579 | - | 1 | - | 5.79 | 0.2280 | 70 | |||
| 9599058 | - | - | - | 5.80 | 0.2283 | ||||
| 9599059 | - | - | - | 5.90 | 0.2323 | 72 | |||
| 8608595 | 15/64 | - | - | 5.95 | 0.2343 | ||||
| 9599060 | - | - | - | 6.00 | 0.2362 | ||||
| 9599061 | - | - | - | 610 | 02402 | ||||
| 9598615 | - | - | - | . 6.15 | . 0.2421 | ||||
| 9599062 | - | - | - | 6.20 | 0.2441 | ||||
| 9599063 | - | - | - | 6.30 | 0.2480 | 31.0 | 75 | 8 | |
| 8608635 | 1/4 | - | E | 6.35 | 0.2500 | ||||
| 9599064 | - | - | - | 6.40 | 0.2520 | ||||
| 9599065 | - | - | - | 6.50 | 0.2559 |
Packed: 1 pc. Available V coating only.
| Work Ma | terial | ||||||||||||||||
| P | M | K | N | S | H | ||||||||||||
| List No | Ca Low | rbon Stee Med. | ls High | Alloy Steels | Die | Sta | inless St | eels | Cast | Alu | minum | Nickel Alloy | Titanium | Hardene | d Steels | ||
| . | 1010 1018 | 1035 1045 | 1065 | 4140 4340 | Steels | 300 | 400 | 17-4 PH | Iron | 6061 7075 | Casting | Inconel | 6Al4V (30 HRC) | ~35 HRC | 35-45 HRC | 45-50 HRC | 50-70 HRC |
| 1900 | |||||||||||||||||
| goo | d | best |
