CNMG 120408 NX	TNMG 160408 NX	CNMG 120408 NN	DNMG 150608 NN
DNMG 150408 NX	TNMG 220408 NX	DNMG 110408 NN	TNMG 160408 NN
DNMG 150608 NX	TNUX 160408 L	DNMG 150408 NN	TNMG 220408 NN

DNUX 150608 R11 TNUX 160408 R KNUX 160405 L / R

Material Group	Lamina Gr. N°	Material Examples	Hardness	DO [m min	C m] max	Fe [mm min	ed /rev] max	V min	c max	Amax [mm2]	Sugg P DOC	ested Sta arameter Feed	rting s Vc
		C35, Ck45,	125 HB				050		330	171		0.36	240
Non Alloyed	1	1020, 1045,	190 HB	0.50	5.00	0.18	.	180	280	.	3.00	0.33	220
		1060, 28Mn6	250 HB				0.45		250	1.42		0.31	200
		42CrMo4,	180 HB		5.00	0.18	0.45		280			0.30	200
L Alld	2	St50, Ck60,	230 HB	00	400			120	250	1.14	3.00		180
P ow oye		4140, 4340,	280 HB	.5	.				210				150
		100Cr6	350 HB		3.50	0.16	0.40		180	0.95	2.70	0.29	130
			220 HB		4.00		0.40		190	1.14		0.29	140
		X40CrMoV5,	280 HB						150				120
High Alloyed	3	H13, M42, D3,	320 HB	0.50		0.16		70	130		2.50		100
		S6-5-2, 12Ni19	350 HB		3.00		0.35		110	0.76		0.27	90
Austenitic	4	304, 316, X5CrNi18-9	180 HB 240 HB	0.50	5.00	0.18	0.40	170 160	270 220	1.14 0.95	3.00	0.24 0.21	190 170
M Duplex	5	X2CrNiN23-4, S31500	290 HB 310 HB	0.50	4.00	0.16	0.35	80 70	150 140	0.76	2.50	0.23	100 90
Ferritic & Martensitic	6	410, X6Cr17, 17-4PH, 430	200 HB 42 HRc	0.50	5.00 4.00	0.16	0.40	170 120	250 190	0.67	2.50 2.20	0.19	190 130
		GG20 GG40	150 HB					170	250	1.90			200
Grey	7	, , EN-GJL-250,	200 HB	0.50	5.00	0.13	0.60	160	230	1.71	3.00	0.33	180
		N030B	250 HB				0.55	150	210	1.71			160
K			150 HB						250	1.42			180
Malleable & Nodular	8	GGG40, GGG70, 50005	200 HB	0.50	5.00	0.13	0.50	120	230	1.24	3.00	0.29	160
			250 HB						190	1.14			140
		Incoloy 800	240 HB						45				32
Fe, Ni & Co based	9	Inconel 700	250 HB	0.50	3.00	0.18	0.35	25	45	0.67	2.00	0.27	30
S		Stellite 21	350 HB					23	40				28
		T40	-		3.50		0.40	35	55	0.76		0.31	45
Ti based	10	TiAl6V4	-	0.50	3.00	0.18	0.35	45	65	0.67	2.00	0.29	55
		X100 CrMo13	45 HRc		2.50		0.30	50	100	0.57	2.00	0.24	80
Steel		, 440C,	50 HRc		2.00		0.25		90	0.38	1.50	0.19	70
H	11	G-X260NiCr42	55 HRc	0.50	1.50	0.10	0.20	40	80	0.28	1.00		60
Chilled Cast Iron		Ni-Hard 2	400 HB		2.00		0.25		60	0.38	1.50	0.17	50
White Cast Iron		G-X300CrMo15	55 HRc		1.50		0.20	30	50	0.28	1.00	0.14	40
NF Aluminium	12	AlSi12	130 HB	0.50	6.00	0.18	0.60	200	400	1.71	3.00	0.38	280

Material Group	Lamina Gr. N°	Material Examples	Hardness	D [m min	OC m] max	Fe [mm min	ed /rev] max	V min	c max	Amax [mm2]	Sug DOC	gested Sta Parameter Feed	rting s Vc
		C35, Ck45,	125 HB				00		330	180		0.38	240
Non Alloyed	1	1020, 1045,	190 HB	0.50	5.00	0.21	.5	180	280	.	3.00	0.35	220
		1060, 28Mn6	250 HB				0.45		250	1.50		0.33	200
		42CrMo4,	180 HB		5.00	0.21	0.45		280			0.32	200
		St50, Ck60,	230 HB						250	1.20	3.00		180
P Low Alloyed	2	4140, 4340,	280 HB	0.50	4.00			120	210				150
		100Cr6	350 HB		3.50	0.18	0.40		180	1.00	2.70	0.30	130
		X40CrMoV5,	220 HB 280 HB		4.00		0.40		190 150	1.20	2.50	0.30	140 120
High Alloyed	3	H13, M42, D3,	320 HB	0.50		0.18		70	130				100
		S6-5-2, 12Ni19	350 HB		3.00		0.35		110	0.80	2.20	0.28	90
		304 316	180 HB					170	270	1.20		0.25	190
Austenitic	4	, , X5CrNi18-9	240 HB	0.50	5.00	0.20	0.40	160	220	1.00	3.00	0.22	170
M Duplex	5	X2CrNiN23-4, S31500	290 HB 310 HB	0.50	4.00	0.18	0.35	80 70	150 140	0.80	2.50	0.24	100 90
Ferritic & Martensitic	6	410, X6Cr17, 17-4PH, 430	200 HB 42 HRc	0.50	5.00 4.00	0.18	0.40	170 120	250 190	0.70	2.50 2.20	0.20	190 130
		GG20 GG40	150 HB					170	250	2.00			200
Grey	7	, , EN-GJL-250,	200 HB	0.50	5.00	0.15	0.60	160	230		3.00	0.35	180
		N030B	250 HB				0.55	150	210	1.80			160
K			150 HB						250	1.50			180
Malleable & Nodular	8	GGG40, GGG70, 50005	200 HB	0.50	5.00	0.15	0.50	120	230	1.30	3.00	0.30	160
			250 HB						190	1.20			140
		Incoloy 800	240 HB						45				32
Fe, Ni & Co based	9	Inconel 700	250 HB	0.50	3.00	0.20	0.35	25	45	0.70	2.00	0.28	30
S		Stellite 21	350 HB					23	40				28
		T40	-		3.50		0.40	35	55	0.80		0.33	45
Ti based	10	TiAl6V4	-	0.50	3.00	0.20	0.35	45	65	0.70	2.00	0.30	55
		X100 CrMo13	45 HRc		2.50		0.30	50	100	0.60	2.00	0.25	80
Steel		, 440C,	50 HRc		2.00		0.25		90	0.40	1.50	0.20	70
H	11	G-X260NiCr42	55 HRc	0.50	1.50	0.11	0.20	40	80	0.30	1.00		60
Chilled Cast Iron		Ni-Hard 2	400 HB		2.00		0.25		60	0.40	1.50	0.18	50
White Cast Iron		G-X300CrMo15	55 HRc		1.50		0.20	30	50	0.30	1.00	0.15	40
NF Aluminium	12	AlSi12	130 HB	0.50	6.00	0.20	0.60	200	400	1.80	3.00	0.40	280
