HOCHLEISTUNGSBOHRER MIT INNENKÜHLUNG
FORET AVEC ARROSAGE INTERNE
PUNTE CON ADDUZIONE REFRIGERANTE
D
ℓ
L
MICRO 10xD R 2
GRAIN 135°
d
6 Facet Point Geometry
| D (mm) h7 | ℓ (mm) | d (mm) h6 | L (mm) | Art. No. (AlTiN NANO coated) |
| 3.00 | 39.0 | 3 | 90 | 865-1181AG1535 |
| 3.10 | 40.3 | 4 | 90 | 865-1220AG1587 |
| 3.20 | 41.6 | 4 | 90 | 865-1260AG1638 |
| 3.30 | 42.9 | 4 | 90 | 865-1299AG1689 |
| 3.40 | 44.2 | 4 | 90 | 865-1339AG1740 |
| 3.50 | 45.5 | 4 | 90 | 865-1378AG1791 |
| 3.60 | 46.8 | 4 | 90 | 865-1417AG1843 |
| 3.70 | 48.1 | 4 | 100 | 865-1457AG1894 |
| 3.80 | 49.4 | 4 | 100 | 865-1496AG1945 |
| 3.90 | 50.7 | 4 | 100 | 865-1535AG1996 |
| 4.00 | 52.0 | 4 | 100 | 865-1575AG2047 |
| 4.10 | 53.3 | 6 | 100 | 865-1614AG2098 |
| 4.20 | 54.6 | 6 | 110 | 865-1654AG2150 |
| 4.30 | 55.9 | 6 | 110 | 865-1693AG2201 |
| 4.40 | 57.2 | 6 | 110 | 865-1732AG2252 |
| 4.50 | 58.5 | 6 | 110 | 865-1772AG2303 |
| 4.60 | 59.8 | 6 | 110 | 865-1811AG2354 |
| 4.70 | 61.1 | 6 | 110 | 865-1850AG2406 |
| 4.80 | 62.4 | 6 | 110 | 865-1890AG2457 |
| 4.90 | 63.7 | 6 | 110 | 865-1929AG2508 |
| 5.00 | 65.0 | 6 | 110 | 865-1969AG2559 |
| 5.10 | 66.3 | 6 | 120 | 865-2008AG2610 |
| 5.20 | 67.6 | 6 | 120 | 865-2047AG2661 |
| 5.30 | 68.9 | 6 | 120 | 865-2087AG2713 |
| 5.40 | 70.2 | 6 | 120 | 865-2126AG2764 |
| 5.50 | 71.5 | 6 | 120 | 865-2165AG2815 |
| 5.60 | 72.8 | 6 | 120 | 865-2205AG2866 |
| 5.70 | 74.1 | 6 | 120 | 865-2244AG2917 |
| 5.80 | 75.4 | 6 | 120 | 865-2283AG2969 |
| 5.90 | 76.7 | 6 | 120 | 865-2323AG3020 |
| 6.00 | 78.0 | 6 | 130 | 865-2362AG3071 |
| 6.10 | 79.3 | 8 | 130 | 865-2402AG3122 |
| 6.20 | 80.6 | 8 | 130 | 865-2441AG3173 |
| 6.30 | 81.9 | 8 | 130 | 865-2480AG3224 |
| 6.40 | 83.2 | 8 | 130 | 865-2520AG3276 |
| 6.50 | 84.5 | 8 | 140 | 865-2559AG3327 |
| 6.60 | 85.8 | 8 | 140 | 865-2598AG3378 |
| 6.70 | 87.1 | 8 | 140 | 865-2638AG3429 |
| 6.80 | 88.4 | 8 | 140 | 865-2677AG3480 |
| 6.90 | 89.7 | 8 | 140 | 865-2717AG3531 |
| 7.00 | 91.0 | 8 | 140 | 865-2756AG3583 |
SERIES 865 WORKPIECE MATERIAL Coating
| Steel | Steel | Hardened Steel | Hardened Steel | Stainless | Cast Iron | Graphite | Copper | CFRP | Plastic | Thermoset | High Density | Nickel / | Titanium | |
| ~30HRC | 30~40HRC | ~55HRC | ~68HRC | Steel | Aluminum | Alloy | Plastic | Plastic | Cobalt | Alloy |
