2020 13.53 13 sous 5xD. conçus pour des profondeurs de forage 4. Les données ci-dessus en coupe sont 0,02 mm. La concentricité doit être inférieure à défectueux. 3. Ne composez jamais un porte-outil l‘utilisation de l‘émulsion. de coupe ci-dessus sont basées sur 2. Les recommandations de données coupe augmentent en conséquence. Avec stable traitement des données de recommandée ou 85% de l‘alimentation. sélectionner 90% de la vitesse de coupe 1. La première fois que vous utilisez depth under 5xD. 4. These conditions above are for cutting 0.02mm. The radial run-out of drill must be under 3. Use a collet without any defect or dust. with emulsion. 2. The cutting conditions above are for drilling and feed rate. stable, gradually increase the cutting speed above. If the cutting conditions remain cutting speed or 85% feed rate mentioned please make a test cutting with 90% of 1. When the tool is used for the first time, Bohrungstiefen unter 5xD ausgelegt. 4. Die obigen Schnittdaten sind für 0,02mm liegen. len. Die Rundlaufgenauigkeit muss unter 3. Keine defekte Werkzeugaufnahme wäh- basieren auf dem Einsatz von Emulsion. 2. Die obigen Schnittdatenempfehlungen erhöhen. arbeitung die Schnittdaten entsprechend des Vorschubes wählen. Bei stabiler Be- lenen Schnittgeschwindigkeit oder 85% 1. Beim ersten Einsatz 90% der empfoh- Données de coupe 3xD Cutting data 3xD Schnittdaten 3xD P H M K N Materialgruppen Wenig legierter Stahl Stahl 30-38HRC Stahl 38-48 HRC Edelstahl GGusseisen Graphit Aluminium Hitzeresistenter Stahl Material groups Low-alloyed steel Steel 30-38HRC Steel 38-48 HRC Stainless Steel Cast Iron Graphite Aluminium Heat resistant steel Groupes matières Acier faible allié Acier 30-38HRC Acier 38-48 HRC Acier inoxydable Fonte Graphite Aluminium Acier thermorésistant Vc 60~120m/min 60~120m/min 40~70m/min 25~40m/min 60~120m/min 50~100m/min 60~140m/min 15~25m/min "Ø „n "f "n "f "n "f "n "f "n "f "n "f "n "f "n "f (mm)" (min-1)“ (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" 3 12700 "0.09~0.12" 12700 "0.09~0.12" 7400 "0.09~0.12" 6300 "0.03~0.07" 12700 "0.09~ 0.12" 9500 "0.09~ 0.12" 15000 "0.09~0.12" 2100 "0.03~ 0.06" 4 9600 "0.10~0.15" 9600 "0.10~0.15" 5600 "0.10~0.15" 4700 "0.04~0.08" 9600 "0.10~ 0.15" 7000 "0.10~ 0.15" 11100 "0.10~0.15" 1600 "0.04~ 0.07" 5 7600 "0.12~0.18" 7600 "0.12~0.18" 4500 "0.12~0.18" 3800 "0.05~0.10" 7600 "0.12~ 0.18" 5700 "0.12~ 0.18" 9000 "0.12~0.18" 1250 "0.05~ 0.09" 6 6400 "0.14~0.20" 6400 "0.14~0.20" 3700 "0.14~0.20" 3200 "0.06~0.12" 6400 "0.14~ 0.20" 4700 "0.14~ 0.20" 7400 "0.14~0.20" 1050 "0.06~ 0.11" 8 4800 "0.16~0.24" 4800 "0.16~0.24" 2800 "0.16~0.24" 2400 "0.08~0.16" 4800 "0.16~ 0.24" 3600 "0.16~ 0.24" 5600 "0.16~0.24" 800 "0.08~ 0.14" 10 3800 "0.18~0.27" 3800 "0.18~0.27" 2200 "0.18~0.27" 1900 "0.10~0.18" 3800 "0.18~ 0.27" 2800 "0.18~ 0.27" 4500 "0.18~0.27" 600 "0.10~ 0.16" 12 3200 "0.20~0.30" 3200 "0.20~0.30" 1900 "0.20~0.30" 1600 "0.12~0.20" 3200 "0.20~ 0.30" 2400 "0.20~ 0.30" 3700 "0.20~0.30" 500 "0.12~ 0.18" 14 2700 "0.22~0.35" 2700 "0.22~0.35" 1600 "0.22~0.35" 1350 "0.13~0.22" 2700 "0.22~ 0.35" 2100 "0.22~ 0.35" 3200 "0.22~0.35" 450 "0.13~ 0.20" 16 2400 "0.25~0.36" 2400 "0.25~0.36" 1400 "0.25~0.36" 1200 "0.14~0.25" 2400 "0.25~ 0.36" 1800 "0.25~ 0.36" 2800 "0.25~0.36" 400 "0.14~ 0.23" 18 2100 "0.28~0.38" 2100 "0.28~0.38" 1200 "0.28~0.38" 1050 "0.15~0.28" 2100 "0.28~ 0.38" 1600 "0.28~ 0.38" 2500 "0.28~0.38" 350 "0.15~ 0.25" 20 1900 "0.30~0.40" 1900 "0.30~0.40" 1100 "0.30~0.40" 950 "0.16~0.30" 1900 "0.30~ 0.40" 1400 "0.30~ 0.40" 2300 "0.30~0.40" 320 "0.16~ 0.28"
