2020 13.45 13 de forage sous 5xD. sont conçus pour des profondeurs 4. Les données ci-dessus en coupe être inférieure à 0,02 mm. défectueux. La concentricité doit 3. Ne composez jamais un porte-outil l‘utilisation de l‘émulsion. de coupe ci-dessus sont basées sur 2. Les recommandations de données mentent en conséquence. ment des données de coupe aug- l‘alimentation. Avec stable traite- coupe recommandée ou 85% de sélectionner 90% de la vitesse de 1. La première fois que vous utilisez depth under 5xD. 4. These conditions above are for cutting under 0.02mm. The radial run-out of drill must be 3. Use a collet without any defect or dust. drilling with emulsion. 2. The cutting conditions above are for rate. increase the cutting speed and feed conditions remain stable, gradually oned above. If the cutting cutting speed or 85% feed rate menti- please make a test cutting with 90% of 1. When the tool is used for the first time, legt. Bohrungstiefen unter 5xD ausge- 4. Die obigen Schnittdaten sind für muss unter 0,02mm liegen. wählen. Die Rundlaufgenauigkeit 3. Keine defekte Werkzeugaufnahme von Emulsion. lungen basieren auf dem Einsatz 2. Die obigen Schnittdatenempfeh- daten entsprechend erhöhen. Bei stabiler Bearbeitung die Schnitt- oder 85% des Vorschubes wählen. fohlenen Schnittgeschwindigkeit 1. Beim ersten Einsatz 90% der emp- Données de coupe 3xD Cutting data 3xD Schnittdaten 3xD P H M K N Materialgruppen Wenig legierter Stahl Stahl 30-38HRC Stahl 38-48 HRC Edelstahl GGusseisen Graphit Aluminium Hitzeresistenter Stahl Material groups Low-alloyed steel Steel 30-38HRC Steel 38-48 HRC Stainless Steel Cast Iron Graphite Aluminium Heat resistant steel Groupes matières Acier faible allié Acier 30-38HRC Acier 38-48 HRC Acier inoxydable Fonte Graphite Aluminium Acier thermorésistant Vc 60~120m/min 60~120m/min 40~70m/min 25~40m/min 60~120m/min 50~100m/min 60~140m/min 15~25m/min "Ø „n "f "n "f "n "f "n "f "n "f "n "f "n "f "n "f (mm)" (min-1)“ (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" (min-1)" (mm/r)" 2 14000 "0.06~0.08" 14000 "0.06~0.08" 9500 "0.06~0.08" 5500 "0.02~0.05" 14000 "0.06~0.08" 11000 "0.06~0.08" 16000 "0.06~0.08" 3200 "0.02~ 0.04" 3 9500 "0.09~0.12" 9500 "0.09~0.12" 6300 "0.09~0.12" 3700 "0.03~0.07" 9500 "0.09~0.12" 7400 "0.09~0.12" 10600 "0.09~0.12" 2100 "0.03~ 0.06" 4 7000 "0.10~0.15" 7000 "0.10~0.15" 4700 "0.10~0.15" 2700 "0.04~0.08" 7000 "0.10~0.15" 5600 "0.10~0.15" 8000 "0.10~0.15" 1600 "0.04~ 0.07" 5 5700 "0.12~0.18" 5700 "0.12~0.18" 3800 "0.12~0.18" 2200 "0.05~0.10" 5700 "0.12~0.18" 4500 "0.12~0.18" 6400 "0.12~0.18" 1250 "0.05~ 0.09" 6 4700 "0.14~0.20" 4700 "0.14~0.20" 3100 "0.14~0.20" 1850 "0.06~0.12" 4700 "0.14~0.20" 3700 "0.14~0.20" 5300 "0.14~0.20" 1050 "0.06~ 0.11" 8 3600 "0.16~0.24" 3600 "0.16~0.24" 2400 "0.16~0.24" 1400 "0.08~0.16" 3600 "0.16~0.24" 2800 "0.16~0.24" 4000 "0.16~0.24" 800 "0.08~ 0.14" 10 2800 "0.18~0.27" 2800 "0.18~0.27" 1900 "0.18~0.27" 1100 "0.10~0.18" 2800 "0.18~0.27" 2200 "0.18~0.27" 3200 "0.18~0.27" 600 "0.10~ 0.16" 12 2400 "0.20~0.30" 2400 "0.20~0.30" 1600 "0.20~0.30" 930 "0.12~0.20" 2400 "0.20~0.30" 1900 "0.20~0.30" 2700 "0.20~0.30" 500 "0.12~ 0.18" 14 2100 "0.22~0.35" 2100 "0.22~0.35" 1400 "0.22~0.35" 800 "0.13~0.22" 2100 "0.22~0.35" 1600 "0.22~0.35" 2300 "0.22~0.35" 450 "0.13~ 0.20" 16 1800 "0.25~0.36" 1800 "0.25~0.36" 1200 "0.25~0.36" 700 "0.14~0.25" 1800 "0.25~0.36" 1400 "0.25~0.36" 2000 "0.25~0.36" 400 "0.14~ 0.23" 18 1600 "0.28~0.38" 1600 "0.28~0.38" 1100 "0.28~0.38" 620 "0.15~0.28" 1600 "0.28~0.38" 1200 "0.28~0.38" 1800 "0.28~0.38" 350 "0.15~ 0.25" 20 1400 "0.30~0.40" 1400 "0.30~0.40" 950 "0.30~0.40" 550 "0.16~0.30" 1400 "0.30~0.40" 1100 "0.30~0.40" 1600 "0.30~0.40" 320 "0.16~ 0.28"
