Solid carbide high performance twist drill
INOX
| l 1 | MICRO | DIN | |
| Нерж сталь | l2 | ||
| < 900 Н/мм | HASTELLOY Полезная длина | GRAIN | 6537 |
| 2 | |||
| 2 ferritic | Effective length | ||
| ФЕРРИТ | Z |
| INOX | d2 | d 1 | 2 | ||
| Специ- | DIN 6535 |
Нерж сталь MONEL альный Form HAK
> 900 Н/мм 2 SPECIAL martensitic куница INOX l 1
l 2
| Нерж сталь | NIMONIC | Полезная длина | |
| < 900 Н/мм 2 | Effective length | 30° |
austenitic Z 140°
| аустенитный | d | d | ||
| 3 | 2 | 1 | 2 |
NI- Ampco HSC
сплав HPC < 900 N/mm2
NI-CO никелево сплав DVC-X12 NICKEL > 900 Н/ мм2 < 500 N/mm2 дающего 4 длинную long chip
Параметры резки Cutting data
5
1325
| Art. | d1 m7 | l3 | l2 | l1 | d2 h6 | € | Art. | d1 m7 | l3 | l2 | l1 | d2 h6 | € |
| 2204090300023 2 9 0 | % 3,0 | 23 | 28 | 66 | 6,0 | 28,80 | 2204090540035 2 9 0 | % 5,4 | 35 | 44 | 82 | 6,0 | 29,40 |
| 2204090300029 2 9 0 | % 3,0 | 29 | 34 | 72 | 6,0 | 39,00 | 2204090540048 2 9 0 | % 5,4 | 48 | 57 | 95 | 6,0 | 45,00 |
| 2204090310023 2 9 0 | % 3,1 | 23 | 28 | 66 | 6,0 | 29,40 | 2204090550035 2 9 0 | % 5,5 | 35 | 44 | 82 | 6,0 | 29,40 |
| 2204090330023 2 9 0 | % 3,3 | 23 | 28 | 66 | 6,0 | 29,40 | 2204090550048 2 9 0 | % 5,5 | 48 | 57 | 95 | 6,0 | 45,00 |
| 2204090340029 2 9 0 | % 3,4 | 29 | 34 | 72 | 6,0 | 39,60 | 2204090560035 2 9 0 | % 5,6 | 35 | 44 | 82 | 6,0 | 29,40 |
| 2204090350023 2 9 0 | % 3,5 | 23 | 28 | 66 | 6,0 | 29,40 | 2204090560048 2 9 0 | % 5,6 | 48 | 57 | 95 | 6,0 | 45,00 |
| 2204090350029 2 9 0 | % 3,5 | 29 | 34 | 72 | 6,0 | 39,60 | 2204090570035 2 9 0 | % 5,7 | 35 | 44 | 82 | 6,0 | 29,40 |
| 2204090360023 2 9 0 | % 3,6 | 23 | 28 | 66 | 6,0 | 29,40 | 2204090570048 2 9 0 | % 5,7 | 48 | 57 | 95 | 6,0 | 45,00 |
| 2204090360029 2 9 0 | % 3,6 | 29 | 34 | 72 | 6,0 | 39,60 | 2204090580035 2 9 0 | % 5,8 | 35 | 44 | 82 | 6,0 | 29,40 |
| 2204090370023 2 9 0 | % 3,7 | 23 | 28 | 66 | 6,0 | 29,40 | 2204090580048 2 9 0 | % 5,8 | 48 | 57 | 95 | 6,0 | 45,00 |
| 2204090370029 2 9 0 | % 3,7 | 29 | 34 | 72 | 6,0 | 39,60 | 2204090590035 2 9 0 | % 5,9 | 35 | 44 | 82 | 6,0 | 29,40 |
| 2204090390029 2 9 0 | % 3,9 | 29 | 36 | 74 | 6,0 | 29,40 | 2204090590048 2 9 0 | % 5,9 | 48 | 57 | 95 | 6,0 | 45,00 |
| 2204090390036 2 9 0 | % 3,9 | 36 | 43 | 81 | 6,0 | 41,40 | 2204090600035 2 9 0 | % 6,0 | 35 | 44 | 82 | 6,0 | 29,40 |
| 2204090400029 2 9 0 | % 4,0 | 29 | 36 | 74 | 6,0 | 29,40 | 2204090600048 2 9 0 | % 6,0 | 48 | 57 | 95 | 6,0 | 45,00 |
| 2204090410029 2 9 0 | % 4,1 | 29 | 36 | 74 | 6,0 | 29,40 | 2204090610043 2 9 0 | % 6,1 | 43 | 53 | 91 | 8,0 | 33,60 |
| 2204090410036 2 9 0 | % 4,1 | 36 | 43 | 81 | 6,0 | 41,40 | 2204090610064 2 9 0 | % 6,1 | 64 | 76 | 114 | 8,0 | 58,80 |
| 2204090420029 2 9 0 | % 4,2 | 29 | 36 | 74 | 6,0 | 29,40 | 2204090620043 2 9 0 | % 6,2 | 43 | 53 | 91 | 8,0 | 33,60 |
| 2204090420036 2 9 0 | % 4,2 | 36 | 43 | 81 | 6,0 | 41,40 | 2204090620064 2 9 0 | % 6,2 | 64 | 76 | 114 | 8,0 | 58,80 |
| 2204090430029 2 9 0 | % 4,3 | 29 | 36 | 74 | 6,0 | 29,40 | 2204090630043 2 9 0 | % 6,3 | 43 | 53 | 91 | 8,0 | 33,60 |
| 2204090430036 2 9 0 | % 4,3 | 36 | 43 | 81 | 6,0 | 41,40 | 2204090630064 2 9 0 | % 6,3 | 64 | 76 | 114 | 8,0 | 58,80 |
| 2204090440036 2 9 0 | % 4,4 | 36 | 43 | 81 | 6,0 | 41,40 | 2204090640043 2 9 0 | % 6,4 | 43 | 53 | 91 | 8,0 | 33,60 |
| 2204090450029 2 9 0 | % 4,5 | 29 | 36 | 74 | 6,0 | 29,40 | 2204090640064 2 9 0 | % 6,4 | 64 | 76 | 114 | 8,0 | 58,80 |
| 2204090450036 2 9 0 | % 4,5 | 36 | 43 | 81 | 6,0 | 41,40 | 2204090650043 2 9 0 | % 6,5 | 43 | 53 | 91 | 8,0 | 33,60 |
| 2204090460029 2 9 0 | % 4,6 | 29 | 36 | 74 | 6,0 | 29,40 | 2204090650064 2 9 0 | % 6,5 | 64 | 76 | 114 | 8,0 | 58,80 |
| 2204090460036 2 9 0 | % 4,6 | 36 | 43 | 81 | 6,0 | 41,40 | 2204090660064 2 9 0 | % 6,6 | 64 | 76 | 114 | 8,0 | 58,80 |
| 2204090470029 2 9 0 | % 4,7 | 29 | 36 | 74 | 6,0 | 29,40 | 2204090670043 2 9 0 | % 6,7 | 43 | 53 | 91 | 8,0 | 33,60 |
| 2204090470036 2 9 0 | % 4,7 | 36 | 43 | 81 | 6,0 | 41,40 | 2204090670064 2 9 0 | % 6,7 | 64 | 76 | 114 | 8,0 | 58,80 |
| 2204090480035 2 9 0 | % 4,8 | 35 | 44 | 82 | 6,0 | 29,40 | 2204090680043 2 9 0 | % 6,8 | 43 | 53 | 91 | 8,0 | 33,60 |
| 2204090480048 2 9 0 | % 4,8 | 48 | 57 | 95 | 6,0 | 45,00 | 2204090680064 2 9 0 | % 6,8 | 64 | 76 | 114 | 8,0 | 58,80 |
| 2204090490048 2 9 0 | % 4,9 | 48 | 57 | 95 | 6,0 | 45,00 | 2204090690043 2 9 0 | % 6,9 | 43 | 53 | 91 | 8,0 | 33,60 |
| 2204090500035 2 9 0 | % 5,0 | 35 | 44 | 82 | 6,0 | 29,40 | 2204090690064 2 9 0 | % 6,9 | 64 | 76 | 114 | 8,0 | 58,80 |
| 2204090500048 2 9 0 | % 5,0 | 48 | 57 | 95 | 6,0 | 45,00 | 2204090700043 2 9 0 | % 7,0 | 43 | 53 | 91 | 80 | 33,60 |
| 2204090510035 2 9 0 | % 5,1 | 35 | 44 | 82 | 6,0 | 29,40 | 2204090700064 2 9 0 | % 7,0 | 64 | 76 | 114 | , 8,0 | 58,80 |
| 2204090510048 2 9 0 | % 5,1 | 48 | 57 | 95 | 6,0 | 45,00 | 2204090710043 2 9 0 | % 7,1 | 43 | 53 | 91 | 8,0 | 33,60 |
| 2204090520035 2 9 0 | % 5,2 | 35 | 44 | 82 | 6,0 | 29,40 | 2204090710064 2 9 0 | % 7,1 | 64 | 76 | 114 | 8,0 | 58,80 |
| 2204090520048 2 9 0 | % 5,2 | 48 | 57 | 95 | 6,0 | 45,00 | 2204090720043 2 9 0 | % 7,2 | 43 | 53 | 91 | 8,0 | 33,60 |
| 2204090530035 2 9 0 | % 5,3 | 35 | 44 | 82 | 6,0 | 29,40 | 2204090720064 2 9 0 | % 7,2 | 64 | 76 | 114 | 8,0 | 58,80 |
| 2204090530048 2 9 0 | % 5,3 | 48 | 57 | 95 | 6,0 | 45,00 | 2204090730043 2 9 0 | % 7,3 | 43 | 53 | 91 | 8,0 | 33,60 |
ES
Минимальный объем заказа для промежуточных размеров: 5 шт / Minimum order volume for intermediate dimensions 5 pieces ? по запросу / on request
