22 0802220802 Твердосплавных сверла высокоэффективная
Solid carbide twist drill
| сталь | l | MICRO | DIN | |
| 1 | ||||
| 2 steel | l2 | GRAIN | 6537 | |
| Полезная длина | ||||
| Effective length | ||||
| INOX | Z | DIN 6535 |
d 2 d N Form HA
Нерж сталь 1 2
STAINLESS STEEL GJL l 1 l2 30° 140°
3 Полезная длина Effective length
| GJS | VTC Z d |
| 2 d 1 2 | |
| GTW | TM-8 |
| GTS | |
| Допуск на диаметр отверстия h7 | |
| Hole tolerance | |
| 4 HRC | > 3-6 +0,000 |
| < 50 | –0,012 |
| > 6-10 +0,000 | |
| коротко- | –0,015 |
| стружеч- | >10-18 +0,000 |
| ного | –0,018 | Параметры резки | Рисунки |
| short chip | Cutting data | Drawings |
5 1324 DXF/STEP
| Art. | d1 h7 | l3 | l2 | l1 | d2 h6 | € | Art. | d1 h7 | l3 | l2 | l1 | d2 h6 | € |
| 2208020300014 2 03 014 | I 3,0 | 14 | 20 | 62 | 6,0 | 15,00 | 2208020510020 2 05 020 | I 5,1 | 20 | 28 | 66 | 6,0 | 17,00 |
| 2208020300023 2 03 023 | I 3,0 | 23 | 28 | 66 | 6,0 | 19,00 | 2208020510035 2 05 035 | I 5,1 | 35 | 44 | 82 | 6,0 | 22,00 |
| 2208020310014 2 03 014 | I 3,1 | 14 | 20 | 62 | 6,0 | 15,00 | 2208020520020 2 05 020 | I 5,2 | 20 | 28 | 66 | 6,0 | 17,00 |
| 2208020310023 2 03 023 | I 3,1 | 23 | 28 | 66 | 6,0 | 19,00 | 2208020520035 2 05 035 | I 5,2 | 35 | 44 | 82 | 6,0 | 22,00 |
| 2208020320014 2 03 014 | I 3,2 | 14 | 20 | 62 | 6,0 | 15,00 | 2208020530020 2 05 020 | I 5,3 | 20 | 28 | 66 | 6,0 | 17,00 |
| 2208020320023 2 03 023 | I 3,2 | 23 | 28 | 66 | 6,0 | 19,00 | 2208020530035 2 05 035 | I 5,3 | 35 | 44 | 82 | 6,0 | 22,00 |
| 2208020330014 2 03 014 | I 3,3 | 14 | 20 | 62 | 6,0 | 15,00 | 2208020540020 2 05 020 | I 5,4 | 20 | 28 | 66 | 6,0 | 17,00 |
| 2208020330023 2 03 023 | I 3,3 | 23 | 28 | 66 | 6,0 | 19,00 | 2208020540035 2 05 035 | I 5,4 | 35 | 44 | 82 | 6,0 | 22,00 |
| 2208020340014 2 03 014 | I 3,4 | 14 | 20 | 62 | 6,0 | 15,00 | 2208020550020 2 05 020 | I 5,5 | 20 | 28 | 66 | 6,0 | 17,00 |
| 2208020340023 2 03 023 | I 3,4 | 23 | 28 | 66 | 6,0 | 19,00 | 2208020550035 2 05 035 | I 5,5 | 35 | 44 | 82 | 6,0 | 24,00 |
| 2208020350014 2 03 014 | I 3,5 | 14 | 20 | 62 | 6,0 | 15,00 | 2208020560020 2 05 020 | I 5,6 | 20 | 28 | 66 | 6,0 | 18,00 |
| 2208020350023 2 03 023 | I 3,5 | 23 | 28 | 66 | 6,0 | 19,00 | 2208020560035 2 05 035 | I 5,6 | 35 | 44 | 82 | 6,0 | 24,00 |
| 2208020360014 2 03 014 | I 3,6 | 14 | 20 | 62 | 6,0 | 15,00 | 2208020570020 2 05 020 | I 5,7 | 20 | 28 | 66 | 6,0 | 18,00 |
| 2208020360023 2 03 023 | I 3,6 | 23 | 28 | 66 | 6,0 | 19,00 | 2208020570035 2 05 035 | I 5,7 | 35 | 44 | 82 | 6,0 | 24,00 |
| 2208020370014 2 03 014 | I 3,7 | 14 | 20 | 62 | 6,0 | 15,00 | 2208020580020 2 05 020 | I 5,8 | 20 | 28 | 66 | 6,0 | 18,00 |
| 2208020370023 2 03 023 | I 3,7 | 23 | 28 | 66 | 6,0 | 19,00 | 2208020580035 2 05 035 | I 5,8 | 35 | 44 | 82 | 6,0 | 24,00 |
| 2208020380017 2 03 017 | I 3,8 | 17 | 24 | 66 | 6,0 | 17,00 | 2208020590020 2 05 020 | I 5,9 | 20 | 28 | 66 | 6,0 | 18,00 |
| 2208020380029 2 03 029 | I 3,8 | 29 | 36 | 74 | 6,0 | 19,00 | 2208020590035 2 05 035 | I 5,9 | 35 | 44 | 82 | 6,0 | 24,00 |
| 2208020390017 2 03 017 | I 3,9 | 17 | 24 | 66 | 6,0 | 17,00 | 2208020600020 2 06 020 | I 6,0 | 20 | 28 | 66 | 6,0 | 18,00 |
| 2208020390029 2 03 029 | I 3,9 | 29 | 36 | 74 | 6,0 | 19,00 | 2208020600035 2 06 035 | I 6,0 | 35 | 44 | 82 | 6,0 | 24,00 |
| 2208020400017 2 04 017 | I 4,0 | 17 | 24 | 66 | 6,0 | 17,00 | 2208020610024 2 06 024 | I 6,1 | 24 | 34 | 79 | 8,0 | 23,00 |
| 2208020400029 2 04 029 | I 4,0 | 29 | 36 | 74 | 6,0 | 19,00 | 2208020610043 2 06 043 | I 6,1 | 43 | 53 | 91 | 8,0 | 33,00 |
| 2208020410017 2 04 017 | I 4,1 | 17 | 24 | 66 | 6,0 | 17,00 | 2208020620024 2 06 024 | I 6,2 | 24 | 34 | 79 | 8,0 | 23,00 |
| 2208020410029 2 04 029 | I 4,1 | 29 | 36 | 74 | 6,0 | 19,00 | 2208020620043 2 06 043 | I 6,2 | 43 | 53 | 91 | 8,0 | 33,00 |
| 2208020420017 2 04 017 | I 4,2 | 17 | 24 | 66 | 6,0 | 17,00 | 2208020630024 2 06 024 | I 6,3 | 24 | 34 | 79 | 8,0 | 23,00 |
| 2208020420029 2 04 029 | I 4,2 | 29 | 36 | 74 | 6,0 | 19,00 | 2208020630043 2 06 043 | I 6,3 | 43 | 53 | 91 | 8,0 | 33,00 |
| 2208020430017 2 04 017 | I 4,3 | 17 | 24 | 66 | 6,0 | 17,00 | 2208020640024 2 06 024 | I 6,4 | 24 | 34 | 79 | 8,0 | 23,00 |
| 2208020430029 2 04 029 | I 4,3 | 29 | 36 | 74 | 6,0 | 19,00 | 2208020640043 2 06 043 | I 6,4 | 43 | 53 | 91 | 8,0 | 33,00 |
| 2208020440017 2 04 017 | I 4,4 | 17 | 24 | 66 | 6,0 | 17,00 | 2208020650024 2 06 024 | I 6,5 | 24 | 34 | 79 | 8,0 | 23,00 |
| 2208020440029 2 04 029 | I 4,4 | 29 | 36 | 74 | 6,0 | 19,00 | 2208020650043 2 06 043 | I 6,5 | 43 | 53 | 91 | 8,0 | 33,00 |
| 2208020450017 2 04 017 | I 4,5 | 17 | 24 | 66 | 6,0 | 17,00 | 2208020660024 2 06 024 | I 6,6 | 24 | 34 | 79 | 8,0 | 23,00 |
| 2208020450029 2 04 029 | I 4,5 | 29 | 36 | 74 | 6,0 | 19,00 | 2208020660043 2 06 043 | I 6,6 | 43 | 53 | 91 | 8,0 | 33,00 |
| 2208020460017 2 04 017 | I 4,6 | 17 | 24 | 66 | 6,0 | 17,00 | 2208020670024 2 06 024 | I 6,7 | 24 | 34 | 79 | 8,0 | 23,00 |
| 2208020460029 2 04 029 | I 4,6 | 29 | 36 | 74 | 6,0 | 19,00 | 2208020670043 2 06 043 | I 6,7 | 43 | 53 | 91 | 8,0 | 33,00 |
| 2208020470017 2 04 017 | I 4,7 | 17 | 24 | 66 | 6,0 | 17,00 | 2208020680024 2 06 024 | I 6,8 | 24 | 34 | 79 | 8,0 | 23,00 |
| 2208020470029 2 04 029 | I 4,7 | 29 | 36 | 74 | 6,0 | 19,00 | 2208020680043 2 06 043 | I 6,8 | 43 | 53 | 91 | 8,0 | 33,00 |
| 2208020480020 2 04 020 | I 4,8 | 20 | 28 | 66 | 6,0 | 17,00 | 2208020690024 2 06 024 | I 6,9 | 24 | 34 | 79 | 8,0 | 22,00 |
| 2208020480035 2 04 035 | I 4,8 | 35 | 44 | 82 | 6,0 | 22,00 | 2208020690043 2 06 043 | I 6,9 | 43 | 53 | 91 | 8,0 | 34,00 |
| 2208020490020 2 04 020 | I 4,9 | 20 | 28 | 66 | 6,0 | 17,00 | 2208020700024 2 07 024 | I 7,0 | 24 | 34 | 79 | 8,0 | 23,00 |
| 2208020490035 2 04 035 | I 4,9 | 35 | 44 | 82 | 6,0 | 22,00 | 2208020700043 2 07 043 | I 7,0 | 43 | 53 | 91 | 8,0 | 34,00 |
| 2208020500020 2 05 020 | I 5,0 | 20 | 28 | 66 | 6,0 | 17,00 | 2208020710029 2 07 029 | I 7,1 | 29 | 41 | 79 | 8,0 | 23,00 |
| 2208020500035 2 05 035 | I 5,0 | 35 | 44 | 82 | 6,0 | 22,00 | 2208020710043 2 07 043 | I 7,1 | 43 | 53 | 91 | 8,0 | 34,00 |
