Solid carbide 4-chamfer twist drill < 40×D
| Сталь | l | MICRO | ||
| 1 | KARNASCH | |||
| steel | l 2 | GRAIN | NORM |
| 2 | < 1200 Н/мм2 | Полезная длина / Effective length | ||
| d2 | d 1 |
INOX Специ- DIN 6535
альный Form HAK Нерж сталь SPECIAL STAINLESS STEEL
Z GJL 2 30° 137°
3
HSC
GJS Сверла толерантности
| h7 | С заданными параметрами закругления краев | HPC | |||
| Drill tolerance | With a defined edge preparation | ||||
| > 3,0 – | +0,000 | ||||
| GTW | 6,0 –0,012 | DVC-X2 | |||
| hp2- | |||||
| GTS | > 6,0 – | +0,000 | finish | ||
| 10,0 | –0,015 | ||||
| коротко- | >10,0 – | +0,000 | |||
| 4 стружеч- | 14,0 | –0,018 |
ного short chip бар
Параметры резки Видео Cutting data Movie
| Art. | d | 1 h7 | l3 | l2 | l1 | d2 h6 | € |
| 2203900300030 2 0 0 | % | 3,0 | 30 | 40 | 80 | 6 | 133,20 |
| 2203900300060 2 0 0 | % | 3,0 | 60 | 65 | 105 | 6 | 136,20 |
| 2203900310045 2 0 0 | % | 3,1 | 45 | 50 | 90 | 6 | 140,40 |
| 2203900340045 2 0 0 | % | 3,4 | 45 | 50 | 90 | 6 | 140,40 |
| 2203900340056 2 0 0 | % | 3,4 | 56 | 60 | 100 | 6 | 140,40 |
| 2203900350050 2 0 0 | % | 3,5 | 50 | 60 | 100 | 6 | 137,40 |
| 2203900350060 2 0 0 | % | 3,5 | 60 | 65 | 105 | 6 | 137,40 |
| 2203900350070 2 0 0 | % | 3,5 | 70 | 75 | 115 | 6 | 141,60 |
| 2203900350144 2 0 1 | % | 3,5 | 144 | 150 | 190 | 6 | 226,20 |
| 2203900360050 2 0 0 | % | 3,6 | 50 | 55 | 100 | 6 | 140,40 |
| 2203900360053 2 0 0 | % | 3,6 | 53 | 68 | 110 | 6 | 150,00 |
| 2203900370050 2 0 0 | % | 3,7 | 50 | 55 | 100 | 6 | 140,40 |
| 2203900370053 2 0 0 | % | 3,7 | 53 | 68 | 110 | 6 | 150,00 |
| 2203900380050 2 0 0 | % | 3,8 | 50 | 55 | 100 | 6 | 140,40 |
| 2203900380053 2 0 0 | % | 3,8 | 53 | 68 | 110 | 6 | 150,00 |
| 2203900390053 2 0 0 | % | 3,9 | 53 | 68 | 110 | 6 | 150,00 |
| 2203900400055 2 0 0 | % | 4,0 | 55 | 65 | 105 | 6 | 146,40 |
| 2203900400085 2 0 0 | % | 4,0 | 85 | 90 | 130 | 6 | 162,00 |
| 2203900400095 2 0 0 | % | 4,0 | 95 | 100 | 140 | 6 | 163,20 |
| 2203900400105 2 0 1 | % | 4,0 | 105 | 110 | 150 | 6 | 183,00 |
| 2203900400120 2 0 1 | % | 4,0 | 120 | 125 | 165 | 6 | 196,20 |
| 2203900400160 2 0 1 | % | 4,0 | 160 | 165 | 210 | 6 | 253,80 |
| 2203900410060 2 0 0 | % | 4,1 | 60 | 65 | 105 | 6 | 146,40 |
| 2203900420060 2 0 0 | % | 4,2 | 60 | 65 | 105 | 6 | 146,40 |
| 2203900420174 2 0 1 | % | 4,2 | 174 | 180 | 225 | 6 | 256,80 |
| 2203900430060 2 0 0 | % | 4,3 | 60 | 65 | 105 | 6 | 146,40 |
| 2203900430073 2 0 0 | % | 4,3 | 73 | 78 | 118 | 6 | 148,80 |
| 2203900440060 2 0 0 | % | 4,4 | 60 | 65 | 105 | 6 | 146,40 |
| 2203900440073 2 0 0 | % | 4,4 | 73 | 78 | 118 | 6 | 148,80 |
| 2203900450060 2 0 0 | % | 4,5 | 60 | 65 | 105 | 6 | 146,40 |
| 2203900450080 2 0 0 | % | 4,5 | 80 | 88 | 130 | 6 | 149,40 |
| 2203900450110 2 0 1 | % | 4,5 | 110 | 118 | 160 | 6 | 171,00 |
| 2203900450184 2 0 1 | % | 4,5 | 184 | 190 | 230 | 6 | 256,80 |
| 2203900460065 2 0 0 | % | 4,6 | 65 | 71 | 110 | 6 | 146,40 |
| 2203900460079 2 0 0 | % | 4,6 | 79 | 85 | 125 | 6 | 162,00 |
| 2203900470065 2 0 0 | % | 4,7 | 65 | 71 | 110 | 6 | 146,40 |
| 2203900470079 2 0 0 | % | 4,7 | 79 | 85 | 125 | 6 | 162,00 |
| 2203900480065 2 0 0 | % | 4,8 | 65 | 71 | 110 | 6 | 146,40 |
| 2203900480079 2 0 0 | % | 4,8 | 79 | 85 | 125 | 6 | 162,00 |
| 2203900490065 2 0 0 | % | 4,9 | 65 | 71 | 110 | 6 | 146,40 |
| 2203900490079 2 0 0 | % | 4,9 | 79 | 85 | 125 | 6 | 162,00 |
| 2203900500070 2 0 0 | % | 5,0 | 70 | 80 | 120 | 6 | 142,80 |
| 2203900500090 2 0 0 | % | 5,0 | 90 | 98 | 140 | 6 | 150,60 |
| 2203900500109 2 0 1 | % | 5,0 | 109 | 115 | 155 | 6 | 171,00 |
| 2203900500120 2 0 1 | % | 5,0 | 120 | 128 | 170 | 6 | 172,80 |
| 2203900510074 2 0 0 | % | 5,1 | 74 | 80 | 120 | 6 | 142,80 |
| 2203900520074 2 0 0 | % | 5,2 | 74 | 80 | 120 | 6 | 142,80 |
| 2203900520088 2 0 0 | % | 5,2 | 88 | 95 | 135 | 6 | 150,60 |
| 2203900530074 2 0 0 | % | 5,3 | 74 | 80 | 120 | 6 | 142,80 |
| 2203900530088 2 0 0 | % | 5,3 | 88 | 95 | 135 | 6 | 150,60 |
| 2203900540074 2 0 0 | % | 5,4 | 74 | 80 | 120 | 6 | 142,80 |
| 2203900550100 2 0 1 | % | 5,5 | 100 | 108 | 150 | 6 | 151,80 |
